Black oxide alloy steel hoist ring with pivoting bail and screw-on bolt

Handi Ramp

Handi Ramp 33312 Hoist Ring 1000 lb WLL

SKU CH-83TX-CPJ29

Alloy-steel hoist ring with 180-degree pivot and 360-degree swivel, rated for 1000 lb working load limit

  • 1,000 lb working load limit for heavy lifts
  • 180° pivot and 360° swivel for multi-angle rigging
  • 12 ft-lb minimum torque ensures secure installation
  • Alloy steel with black oxide finish resists corrosion
  • Removable bolt included for quick attachment

Heavy-Duty Hoist Ring 1000 lb WLL

The Handi Ramp 33312 is an ADB Hoist Ring rated for a 1000 lb working load limit. It is built from alloy steel with a black oxide finish for lifting and pulling tasks. The bail pivots 180 degrees and swivels 360 degrees to keep the load aligned. A removable bolt and hardware are included for screw-on mounting.

Check Thread Size and Torque Before Installing

Verify that the mounting point accepts a 3/8 In. -16 thread with at least 1/2 in of usable thread engagement. The installation requires a minimum torque of 12 ft-lb to secure the ring properly. Confirm the bail inside dimensions of 1 1/2 in length and 1 1/4 in width suit your hook or shackle. Ensure the pivot and swivel movement is not obstructed by surrounding structure.

Suits Fixed-Point Lifting With Angular Adjustment

This ring suits riggers who need a single anchor that aligns itself under load through full pivot and swivel travel. It is not for applications requiring a higher working load limit than 1000 lb. Buyers needing a different thread specification or a non-removable bolt should look at alternative anchor points. The fixed overall length and width of 2 1/4 in may not fit confined mounting patterns.

Highlights

  • 1,000 lb working load limit for heavy lifts
  • 180° pivot and 360° swivel for multi-angle rigging
  • 12 ft-lb minimum torque ensures secure installation
  • Alloy steel with black oxide finish resists corrosion
  • Removable bolt included for quick attachment

Specifications

BrandADB HOIST RINGS

Questions about this item

Does the 33312 hoist ring come with the mounting bolt or must I order one separately?

The removable bolt is included, so no extra mounting hardware is required for installation.

When should I choose the 1000 lb WLL version versus a higher-capacity ring?

Select this 1000 lb WLL ring when the applied load will not exceed 1000 lb; move to a higher-rated ring for heavier loads.

What does the 1000 lb working load limit mean once the ring is torqued to 12 ft-lb on my equipment?

At the specified 12 ft-lb installation torque the ring is rated to safely support 1000 lb through a full 180-degree pivot and 360-degree swivel.
