GE TED136040WL 40A 3 Pole 600V AC Molded Case Circuit Breaker

SKU CH-7H4A-9MXFR

Three-pole thermal-magnetic breaker rated 40 A at 600 V AC with 18 kA interrupting capacity, bolt-on mounting for GE panelboards

  • 40 A rating protects three-phase circuits up to 600 V AC
  • 18 kA interrupting capacity clears faults on 120, 240, 277 and 480 V systems
  • Thermal-magnetic trip provides overload and short-circuit protection without adjustment
  • Bolt-on mounting fits GE panelboards with 150 A frame size
  • Line and load lug terminals accept cable directly for simple installation

Application Scope

The GE TED136040WL is a 40 A, three-pole molded case circuit breaker rated for 600 V AC and 500 V DC. It uses a thermal-magnetic trip unit with fixed instantaneous settings to protect three-phase feeders or branch circuits in GE panelboards. The 150 A frame size and bolt-on mounting suit industrial and commercial power distribution boards.

Upgrade Context

This unit replaces a lower-rated breaker when a circuit is uprated to 40 A or when a worn device must be swapped within the same TED series footprint. The jump is worthwhile when the panelboard accepts a 150 A frame bolt-on and the available interrupting rating of 18 kA at 480 V AC meets the system fault current requirement.

Sustained Operation

Thermal-magnetic operation provides consistent overload protection during prolonged loading without nuisance tripping. The fixed instantaneous trip responds predictably to short-circuit currents up to the 18 kA rating at 277 V and 480 V AC. Lug terminals on line and load sides maintain secure connections through thermal cycling in the enclosure.

Highlights

  • 40 A rating protects three-phase circuits up to 600 V AC
  • 18 kA interrupting capacity clears faults on 120, 240, 277 and 480 V systems
  • Thermal-magnetic trip provides overload and short-circuit protection without adjustment
  • Bolt-on mounting fits GE panelboards with 150 A frame size
  • Line and load lug terminals accept cable directly for simple installation

Specifications

BrandGE

Questions about this item

Will the 6.31 in height and 4.13 in width fit my GE bolt-on panelboard?

Yes — the breaker measures 6.31 in high by 4.13 in wide by 4.09 in deep and uses a bolt-on mounting style made for GE panelboards.

What is the correct torque for the line/load lugs so I don't over-tighten them?

Torque the line/load lugs to the value printed on the breaker label or in the GE TED installation sheet; the most common error is using a generic torque instead of the labeled value.

How often should I exercise or test the 40 A thermal-magnetic trip unit?

Manually operate the handle once a year and verify trip function per your facility's preventive-maintenance schedule; replace the unit if it fails to trip at its 40 A rating.
