Red rectangular aluminum connection block with multiple G1/2 ports

Festo

Festo VABM-B10-30S-G12-9-P3 8026420 connection block

SKU CH-3QCT-HTHH4 MPN VABM-B10-30S-G12-9-P3

A G1/2 pneumatic connection block with nine valve positions, 32 mm width and 2193 g weight

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 9 valve positions supported for flexible pneumatic layouts
  • G1/2 ports on connections 1 and 3 simplify system integration
  • Wrought aluminium alloy rail resists corrosion in moderate environments
  • 32 mm width allows compact manifold mounting in tight spaces
  • RoHS-compliant materials meet environmental substance restrictions

Pneumatic manifold for valve mounting

The Festo VABM-B10-30S-G12-9-P3 is a connection block designed to mount up to nine valve positions in a single manifold rail. It suits engineers building compact pneumatic control systems for automation equipment. The manifold accepts G1/2 pneumatic connections at ports 1 and 3 for supply and exhaust routing. Mounting orientation is unrestricted, allowing installation in any position.

Nine valve positions on one rail

The decisive specification is the maximum of nine valve positions supported by this manifold. Builders needing fewer stations can leave ports blank, but applications requiring ten or more valves must use multiple manifolds or a different rail length. The 32 mm width dimension determines the overall footprint and valve spacing. This fixed capacity defines whether the part fits the machine design.

Aluminium rail with moderate corrosion resistance

The manifold rail is made from wrought aluminium alloy and carries a corrosion resistance class of CRC 2 for moderate corrosion stress environments. It weighs 2193 g and meets RoHS material compliance. Mounting uses through-holes for secure attachment. No active cooling or power draw is involved, so thermal and noise considerations do not apply during normal pneumatic operation.

Highlights

  • 9 valve positions supported for flexible pneumatic layouts
  • G1/2 ports on connections 1 and 3 simplify system integration
  • Wrought aluminium alloy rail resists corrosion in moderate environments
  • 32 mm width allows compact manifold mounting in tight spaces
  • RoHS-compliant materials meet environmental substance restrictions

Specifications

BrandFESTO
ModelVABM-B10-30S-G12-9-P3 8026420
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What does the nine-valve-position capacity mean for a real pneumatic manifold?

The block provides nine discrete valve stations on a single rail, so you can mount up to nine valves and supply them from the common G1/2 ports without additional manifold sections.

How does the G1/2 pneumatic connection limit airflow in practice?

Each G1/2 port caps the maximum flow to what a half-inch BSP thread can deliver; the manifold itself does not impose a lower restriction beyond that port size.

What physical mounting does the 32 mm wide rail require?

The rail uses through-holes for bolt-on mounting in any orientation and weighs 2193 g, so plan for adequate support on the mounting surface.
