Festo VABM-B10-25E-G12-6 8026247 Connection Block

Connection block for valve manifolds

The Festo VABM-B10-25E-G12-6 is a pneumatic connection block designed to integrate electrical and air supply for valve terminal assemblies. It features a G1/2 port size and supports up to 12 valve positions in a single manifold layout. The red finished housing identifies the unit within the VABM series for quick visual reference during installation. Supplied as a single unit in boxed packaging.

Suits pneumatic panel builders.

This block suits control-panel builders assembling mid-to-large valve islands that require a common G1/2 supply and up to 12 addressable stations. It is not intended for compact machines needing only a few valve positions or for systems using smaller port standards such as G1/4 or push-in fittings. Buyers requiring integrated fieldbus electronics or diagnostic LEDs should verify compatibility with their specific valve series before ordering.

G1/2 port with 12-station capacity

The defining specification is the G1/2 thread combined with a 12-station manifold capacity, which fixes both the flow envelope and the maximum number of valves the block can serve. Matching this port size and station count to the system design determines whether the VABM-B10-25E-G12-6 fits the application.
