Festo EZH-2,5/9-20-B 164992 Flat Cylinder

Festo EZH Flat Cylinder for Test Applications

The Festo EZH-2,5/9-20-B 164992 is a new flat cylinder supplied as a single unit in a red finish. It is categorised as electrician test equipment and suits technicians who need a compact pneumatic actuator for measurement or positioning tasks. The pack contains one cylinder ready for integration into existing compressed-air systems. The three-year parts coverage and one-year labour term reflect the manufacturer's standard support period.

Sustained Operation with Standard Pneumatic Supply

Under continuous cycling the cylinder maintains consistent stroke behaviour provided the supply pressure remains within the rated range. Heat build-up is minimal because the flat profile presents a large surface area relative to the internal volume. No external cooling is required for typical duty cycles. The sealed construction resists contamination in workshop environments.

Replaces Bulkier Round-Body Actuators in Tight

The flat body allows installation where a conventional round cylinder would foul adjacent components or exceed the available depth. The upgrade is worthwhile when panel space is restricted and the required force falls within the cylinder's output range. It does not suit applications that demand a longer stroke than the 20 mm specification or a higher force than the bore permits. Builders needing a different stroke length or mounting pattern should select an alternative model.
