Red flat cylinder, model DZF-12-40-P-A, part 164005

Festo

Festo DZF-12-40-P-A 164005 Flat Cylinder electrician tool

SKU CH-A9CP-TNSCN MPN DZF-12-40-P-A

Flat cylinder for electrician test equipment, 12 mm bore and 40 mm stroke, supplied new in a single box

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 12 mm bore fits tight spaces
  • 40 mm stroke delivers precise linear motion
  • Flat cylinder profile suits low-clearance installs
  • Festo pneumatic reliability for electrician tasks
  • New unit ready for immediate deployment

Flat cylinder for pneumatic systems

The Festo DZF-12-40-P-A is a compact flat cylinder designed for linear motion in pneumatic automation. It uses a 12 mm bore and a 40 mm stroke to deliver controlled push or pull force. The unit arrives new in a single pack identified by part number 164005. Its red finish matches standard Festo component colour coding.

Suited for tight-space automation tasks

Engineers building machinery with restricted installation height will value the low-profile body. Maintenance teams needing a direct replacement for the same part number can install it without redesign. Buyers who require a longer stroke, a different bore diameter or a double-acting variant with adjustable cushioning should look at other models in the range.

12 mm bore with 40 mm stroke defines fit

The bore and stroke combination fixes the cylinder’s force output and travel distance. These two dimensions determine whether the actuator fits the mechanical envelope and meets the load requirement. Verify both values against your design drawings before ordering.

Highlights

  • Compact 12 mm bore fits tight spaces
  • 40 mm stroke delivers precise linear motion
  • Flat cylinder profile suits low-clearance installs
  • Festo pneumatic reliability for electrician tasks
  • New unit ready for immediate deployment

Specifications

BrandFESTO
ModelDZF-12-40-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What does the 12 mm bore and 40 mm stroke mean for the force and speed of this flat cylinder?

The 12 mm bore and 40 mm stroke determine the piston area and travel distance, which together with the supply pressure set the maximum force and extension speed.

What mounting pattern and thread size are required to install the DZF-12-40-P-A on a machine frame?

The cylinder uses the standard Festo flat-cylinder mounting holes and thread dimensions for the 12 mm bore size; check the catalogue drawing for exact hole centres and thread pitch.

How is the pneumatic connection made on this model, and which port thread do I need to fit?

Connect compressed air to the threaded ports on the cylinder body; the port thread matches the 12 mm bore series, so use the matching push-in fitting or adapter for your tubing.
