Red Festo ISO cylinder DSBG-40-100-PPSA-N3 1646563

Festo

Festo DSBG-40-100-PPSA-N3 40 100 1646563 electrician tool

SKU CH-GWEK-DG0GS MPN DSBG-40-100-PPSA-N3

ISO cylinder with 40 mm bore and 100 mm stroke for pneumatic automation systems

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • ISO cylinder for standardised pneumatic systems
  • 40 mm bore and 100 mm stroke for precise linear motion
  • Red finish aids quick visual identification in the workshop
  • Supplied as a single unit in protective box packaging
  • Backed by three-year parts and one-year labour coverage

Festo ISO Cylinder 40 100

The Festo DSBG-40-100-PPSA-N3 is a new ISO standard cylinder supplied as a single unit in a box. It carries part number 1646563 and features a red finish. This pneumatic actuator is built for industrial automation and machinery applications.

Automation engineers and maintenance teams

This cylinder suits engineers specifying ISO-compliant linear motion for new builds or scheduled overhauls. It is not for buyers needing a complete actuation kit with mountings or sensors included. Operations requiring a different bore or stroke length should select an alternative model.

Bore 40 mm stroke 100 mm

The bore diameter is 40 mm and the stroke length is 100 mm. These two dimensions determine whether the cylinder fits the mechanical envelope and delivers the required travel. Verify both values against your design drawings before ordering.

Highlights

  • ISO cylinder for standardised pneumatic systems
  • 40 mm bore and 100 mm stroke for precise linear motion
  • Red finish aids quick visual identification in the workshop
  • Supplied as a single unit in protective box packaging
  • Backed by three-year parts and one-year labour coverage

Specifications

BrandFESTO
ModelDSBG-40-100-PPSA-N3
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What pneumatic fittings and tubing sizes match the DSBG-40-100-PPSA-N3 ports?

The cylinder uses standard ISO pneumatic ports; select push-in fittings and tubing rated for your system pressure that match the port thread size shown in the Festo datasheet for this model.

Will the 40 mm bore and 100 mm stroke align with my existing ISO cylinder mounts?

The DSBG-40-100-PPSA-N3 follows the ISO cylinder envelope for its bore and stroke, so it fits the same mounting pattern and centre-to-centre distances as other ISO cylinders of the same bore and stroke.

How can I verify the cylinder is operating correctly after installation?

Pressurise the system and confirm smooth full-stroke extension and retraction at the expected speed, check for air leaks at the ports and seals, and verify the position sensor (if fitted) switches cleanly at both end positions.
