Red ISO cylinder in a box, new condition

Festo

Festo DSBC-50-100-D3-PPSA-N3 ISO Cylinder 50 100

SKU CH-RHK1-NQPM0 MPN DSBC-50-100-D3-PPSA-N3

ISO cylinder with a 50 mm bore and 100 mm stroke, supplied new in a single pack

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • ISO cylinder with 50 mm bore and 100 mm stroke
  • Festo manufacturing ensures reliable pneumatic performance
  • Red finish provides clear visual identification in systems
  • Supplied as a single unit in protective box
  • Manufacturer part 3659499 simplifies ordering and replacement

ISO Cylinder 50 mm Bore 100 mm Stroke

The Festo DSBC-50-100-D3-PPSA-N3 is a standard ISO pneumatic cylinder built for linear motion tasks in automation and machine building. It suits engineers and technicians who need a reliable actuator with a 50 mm bore and 100 mm stroke for clamping, pushing or positioning work. The unit ships new in a single pack under part number 3659499.

Mounting and Integration

The cylinder follows ISO mounting dimensions so it fits standard brackets, foot mounts or trunnion kits without custom machining. Its red finish aids visual identification in crowded control cabinets. The package contains one cylinder; sensors, fittings and tubing are sourced separately to complete the pneumatic circuit.

Operation and Maintenance

Normal operation uses compressed air within the pressure range defined by the ISO standard for this bore size. The sealed construction keeps contamination out, reducing leakage and extending service intervals. Festo backs the parts for three years and labour for one year, reflecting confidence in the cylinder's durability under typical cycling loads.

Highlights

  • ISO cylinder with 50 mm bore and 100 mm stroke
  • Festo manufacturing ensures reliable pneumatic performance
  • Red finish provides clear visual identification in systems
  • Supplied as a single unit in protective box
  • Manufacturer part 3659499 simplifies ordering and replacement

Specifications

BrandFESTO
ModelDSBC-50-100-D3-PPSA-N3
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What stroke length does the DSBC-50-100-D3-PPSA-N3 provide before it reaches its mechanical limit?

The cylinder delivers a 100 mm stroke, so the piston travels that distance before hitting the end caps.

How much compressed air does the ISO cylinder consume during continuous cycling?

Air consumption depends on supply pressure and cycle rate; the unit itself has no integrated compressor or flow meter.

Which mounting accessories must be on hand to install the DSBC-50-100-D3-PPSA-N3?

You will need ISO-compatible mounting brackets or clevis pins that match the 50 mm bore pattern.
