Red Festo ISO cylinder, model DNC-125-320-PPV-A, part 163506

Festo

Festo DNC-125-320-PPV-A ISO Cylinder 163506

SKU CH-PB24-PEZQ1 MPN DNC-125-320-PPV-A

ISO cylinder with 125 mm bore and 320 mm stroke for pneumatic automation tasks

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • ISO cylinder for standardised mounting
  • 125 mm bore delivers high force output
  • 320 mm stroke suits long travel needs
  • Red finish aids visual identification in systems
  • New unit with manufacturer part number 163506

ISO Cylinder Specifications

The Festo DNC-125-320-PPV-A is a standard ISO pneumatic cylinder with a 125 mm bore and a 320 mm stroke. It is supplied new in a single box under part number 163506. The unit features a red finish and is classified as test equipment for pneumatic systems.

Suitable Applications

This cylinder suits engineers specifying ISO-compliant linear actuators for automation or machinery builds. Buyers needing a different bore diameter, stroke length or mounting style should look at other models. The three-year parts and one-year labor coverage applies only to this specific configuration.

Decisive Specification

The 125 mm bore combined with the 320 mm stroke defines the force output and travel distance for the application. Confirm these two values match the design requirements before ordering. No other dimensions or performance figures are provided in the data.

Highlights

  • ISO cylinder for standardised mounting
  • 125 mm bore delivers high force output
  • 320 mm stroke suits long travel needs
  • Red finish aids visual identification in systems
  • New unit with manufacturer part number 163506

Specifications

BrandFESTO
ModelDNC-125-320-PPV-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What does the 125 in the model number tell me about which cylinder to choose?

The 125 indicates a 125 mm bore size, which determines the force output at a given pressure. Select this bore when your application calculations call for that specific force range.

How does the 320 mm stroke perform once the cylinder is installed in a machine?

The 320 mm stroke provides 320 mm of linear travel. In practice this means the piston rod extends and retracts over that full distance, so the machine frame must accommodate the extended and retracted lengths.

Which ISO standard applies to the DNC-125-320-PPV-A and what does it cap in practice?

The cylinder follows ISO cylinder standards, which define mounting dimensions and rod-end threads. This caps the physical envelope and connection points, ensuring it fits standard ISO mountings and accessories.
