Red Festo guided actuator, compact rectangular body, model DFM-32-20-P-A-GF

Festo

Festo DFM-32-20-P-A-GF 170854 Guided Actuator

SKU CH-9CCX-5AW5V MPN DFM-32-20-P-A-GF

Guided actuator with 32 mm bore and 20 mm stroke for precise linear motion

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Guided actuator with 32 mm bore for precise linear motion
  • 20 mm stroke length enables compact installation
  • Red finish identifies Festo pneumatic components at a glance
  • Single-unit box packaging simplifies inventory handling
  • Manufacturer part 170854 ensures exact replacement ordering

Guided actuator for precision motion

The Festo DFM-32-20-P-A-GF is a guided actuator built for linear movement tasks that require stable guidance. It integrates a cylinder with a built-in guide to resist side loads and maintain alignment. The unit is supplied new in a single pack under part number 170854.

Automation engineers and machine builders

This actuator suits engineers designing pick-and-place units, feeding systems or assembly modules where guided stroke is essential. It is not for applications needing rotary motion, high-speed positioning without external control or environments outside the rated operating conditions.

32 mm bore with 20 mm stroke

The bore diameter is 32 mm and the stroke length is 20 mm, defining the force capacity and travel range. These two figures determine whether the actuator fits the mechanical layout and load profile of your application.

Highlights

  • Guided actuator with 32 mm bore for precise linear motion
  • 20 mm stroke length enables compact installation
  • Red finish identifies Festo pneumatic components at a glance
  • Single-unit box packaging simplifies inventory handling
  • Manufacturer part 170854 ensures exact replacement ordering

Specifications

BrandFESTO
ModelDFM-32-20-P-A-GF
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Should I choose the 20 mm or 32 mm variant of the DFM guided actuator?

The model DFM-32-20-P-A-GF combines a 32 mm bore with a 20 mm stroke; select this part number when that exact bore and stroke combination matches your application.

What does the 20 mm stroke mean once the actuator is installed in a machine?

The 20 mm stroke defines the linear travel distance the guided piston rod will extend and retract during each cycle.

Which pneumatic interface standard does the DFM-32-20-P-A-GF use and what does it limit?

It uses standard pneumatic ports sized for the 32 mm bore, which caps the maximum flow rate and operating pressure to the values rated for that bore size.
