Red compact air cylinder model AEVUZ-100-20-P-A in box

Festo

Festo AEVUZ-100-20-P-A 157250 Compact Air Cylinder

SKU CH-06H1-0CYZM MPN AEVUZ-100-20-P-A

Compact air cylinder with a 100 mm bore and 20 mm stroke for linear motion tasks

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact air cylinder delivers precise linear motion with 20 mm stroke
  • 100 mm bore diameter provides high force output for demanding tasks
  • Festo engineering ensures reliable pneumatic performance in automated systems
  • Red finish allows quick visual identification in complex assemblies
  • Supplied as a single unit in protective box packaging

Compact air cylinder for pneumatic systems

The Festo AEVUZ-100-20-P-A is a compact air cylinder designed for linear motion in automated machinery. It delivers a 100 mm bore and 20 mm stroke within a space-saving body. The unit arrives new in a single pack, identified by part number 157250, ready for installation in pneumatic circuits. Red finish provides visual identification in complex assemblies.

Suited for short-stroke automation tasks

This cylinder suits engineers building pick-and-place units, clamping fixtures or other short-travel actuators where a 20 mm stroke is sufficient. It is not for applications requiring longer travel, higher force from a larger bore, or non-pneumatic actuation methods such as electric linear drives. Buyers needing different stroke lengths or bore sizes must select an alternative model.

20 mm stroke defines the travel limit

The 20 mm stroke is the single specification that determines whether this cylinder fits the intended motion profile. Only choose this part when the required linear displacement matches this exact travel distance.

Highlights

  • Compact air cylinder delivers precise linear motion with 20 mm stroke
  • 100 mm bore diameter provides high force output for demanding tasks
  • Festo engineering ensures reliable pneumatic performance in automated systems
  • Red finish allows quick visual identification in complex assemblies
  • Supplied as a single unit in protective box packaging

Specifications

BrandFESTO
ModelAEVUZ-100-20-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Will the AEVUZ-100-20-P-A cylinder fit existing 100 mm bore mounts?

The cylinder is built to a 100 mm bore standard, so it matches mounts made for that bore size. Check your current mounting pattern and rod thread to confirm alignment before installation.

How can I verify the AEVUZ-100-20-P-A is operating correctly after installation?

Pressurise the system and run the cylinder through its 20 mm stroke. Movement should be smooth, repeatable and free of air leaks at the ports or seals.

What comes in the box with the AEVUZ-100-20-P-A and what must I source separately?

The box contains one compact air cylinder. Fittings, tubing, mounting brackets and flow controls are not included and must be purchased separately.
