Red Festo compact cylinder, 63mm bore, 25mm stroke

Festo

Festo ADVU-63-25-P-A Compact Cylinder 63mm Bore 25mm Stroke

SKU CH-8HNB-BR0HN MPN ADVU-63-25-P-A

Compact pneumatic cylinder with 63 mm bore and 25 mm stroke for linear actuation

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact cylinder with 63 mm bore for high force output
  • 25 mm stroke length enables precise short-travel motion
  • Festo part 156562 ensures exact replacement compatibility
  • Red finish provides clear visual identification on site
  • Supplied as a single unit in a protective box

Compact cylinder for automation

The Festo ADVU-63-25-P-A is a compact pneumatic cylinder with a 63mm bore and 25mm stroke. It suits machine builders and maintenance engineers who need short-stroke linear actuation in tight spaces. The unit arrives new in a single box under part number 156562.

Upgrade from larger tie-rod units

This cylinder replaces bulkier tie-rod actuators when mounting room is limited and the required stroke is 25mm or less. The jump is worth it when cycle rates demand a lighter moving mass and the application fits the compact envelope.

Direct mount with standard threads

Installation uses the cylinder’s own threaded body and end-cap ports for direct mounting and piping. Common issues include over-tightening fittings into the ports and misaligning the load, which causes side-loading wear on the piston rod.

Highlights

  • Compact cylinder with 63 mm bore for high force output
  • 25 mm stroke length enables precise short-travel motion
  • Festo part 156562 ensures exact replacement compatibility
  • Red finish provides clear visual identification on site
  • Supplied as a single unit in a protective box

Specifications

BrandFesto
ModelADVU-63-25-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What mounting dimensions does the 63 mm bore cylinder require?

The cylinder has a 63 mm bore and 25 mm stroke; mounting holes follow the standard pattern for this bore size.

Which step is most often missed when installing the ADVU-63-25-P-A?

Ensure the piston rod is fully retracted and the air supply is off before tightening the flange bolts to the specified torque.

When should the seals on this compact cylinder be replaced?

Plan seal replacement after three years of service or sooner if leakage appears at the rod or end caps.
