Red compact air cylinder, model ADN-40-15-I-P-A, part number 536301

Festo

Festo ADN-40-15-I-P-A 536301 Compact Air Cylinder

SKU CH-FFA6-5DCG5 MPN ADN-40-15-I-P-A

Compact air cylinder with a 40 mm bore and 15 mm stroke for pneumatic motion control

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 40 mm bore fits tight machine spaces
  • 15 mm stroke delivers precise short travel
  • Piston-rod design provides reliable linear force
  • Red finish allows quick visual identification
  • New condition ensures full factory performance

Compact Air Cylinder for Pneumatic Systems

The Festo ADN-40-15-I-P-A is a compact air cylinder designed for pneumatic automation tasks. It carries model number 536301 and is supplied as a single unit in a box. The component is new and finished in red.

Integration into Automated Machinery

This cylinder fits into builds that require short-stroke linear actuation using compressed air. It needs a compatible pneumatic circuit with fittings and tubing matched to its ports. The compact body frees up space in tight machine frames or fixture assemblies.

Suited for Space-Constrained Actuation

Engineers specifying compact pneumatic actuators for new machine builds will find this cylinder appropriate. Buyers who need longer stroke lengths or different mounting styles should look at other models. Those requiring electric actuation instead of pneumatic power should consider alternative technologies.

Highlights

  • Compact 40 mm bore fits tight machine spaces
  • 15 mm stroke delivers precise short travel
  • Piston-rod design provides reliable linear force
  • Red finish allows quick visual identification
  • New condition ensures full factory performance

Specifications

BrandFESTO
ModelADN-40-15-I-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What is the 15 mm stroke limit of the ADN-40-15-I-P-A cylinder?

The ADN-40-15-I-P-A compact air cylinder has a 15 mm stroke, which defines its maximum linear travel distance during operation.

How much compressed air does the ADN-40-15-I-P-A consume during continuous cycling?

Air consumption depends on operating pressure and cycle frequency; the cylinder itself has no integrated flow meter or consumption rating.

Which pneumatic fittings and tubing are required to connect the ADN-40-15-I-P-A?

The cylinder uses standard pneumatic ports; you need compatible push-in fittings and tubing matched to your supply pressure and thread size.
