Red compact air cylinder ADN-40-15-A-P-A 536291

Festo

Festo ADN-40-15-A-P-A 536291 Compact Air Cylinder

SKU CH-FDSF-BCWZH MPN ADN-40-15-A-P-A

Compact air cylinder with 40 mm bore and 15 mm stroke for pneumatic systems

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 40 mm bore suits tight machine spaces
  • 15 mm stroke for precise short-travel motion
  • Festo pneumatic quality ensures reliable cycling
  • Red finish aids quick visual identification on line
  • Part number 536291 simplifies ordering and spares tracking

Compact air cylinder for pneumatic systems

The Festo ADN-40-15-A-P-A is a compact air cylinder built for automated motion tasks. It suits engineers and technicians who need reliable linear actuation in tight machine envelopes. The unit arrives new in a single pack identified by part number 536291.

Check mounting pattern and stroke needs

Verify that the 40 mm bore and 15 mm stroke match the mechanical layout before ordering. Confirm the available air pressure range and port thread type against your circuit design. Ensure the cylinder’s physical envelope fits the allotted space without interference.

Replaces worn or undersized actuators

This cylinder replaces damaged units of the same bore and stroke to restore original motion profiles. It also upgrades from smaller-bore actuators when the application demands higher force at the same pressure. The change is worth it when the existing cylinder cannot deliver the required push or pull load.

Highlights

  • Compact 40 mm bore suits tight machine spaces
  • 15 mm stroke for precise short-travel motion
  • Festo pneumatic quality ensures reliable cycling
  • Red finish aids quick visual identification on line
  • Part number 536291 simplifies ordering and spares tracking

Specifications

BrandFESTO
ModelADN-40-15-A-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What comes in the box with the ADN-40-15-A-P-A and what must I buy separately?

The box contains one compact air cylinder, model ADN-40-15-A-P-A, part number 536291. Fittings, tubing and a compressed-air supply are not included and must be sourced separately.

How do I choose between the available versions of this cylinder?

The supplier lists a single version: ADN-40-15-A-P-A with a 40 mm bore and 15 mm stroke. No alternative bore or stroke options are offered for this part number.

What does the 15 mm stroke mean when the cylinder is installed in a machine?

The 15 mm stroke is the maximum linear travel the piston rod can extend from its fully retracted position. The cylinder will move a load through that distance each time it is actuated.
