Red compact air cylinder 32mm bore 10mm stroke

Festo

Festo ADN-32-10-A-P-A 32mm 10mm stroke compact air cylinder

SKU CH-9ZTZ-A9B1G MPN ADN-32-10-A-P-A

A compact pneumatic cylinder with a 32 mm bore and 10 mm stroke, supplied new in a single box

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 32 mm bore fits tight machine spaces
  • 10 mm stroke enables precise short movements
  • Compact design reduces overall assembly footprint
  • Festo 536269 part ensures correct replacement identification
  • Red finish allows quick visual identification in systems

Compact 32 mm air cylinder for short-stroke

The Festo ADN-32-10-A-P-A is a compact pneumatic cylinder with a 32 mm bore and a 10 mm stroke. It suits automation tasks that need short, repeatable linear motion in tight machine envelopes. The unit is supplied new in a single pack under part number 536269.

Practical limits of the short stroke

A 10 mm stroke restricts travel to very small positioning or clamping steps. The cylinder cannot replace longer-stroke actuators for feed, lift or ejection cycles that need more displacement. Designers must plan the surrounding mechanism to deliver useful work within this fixed distance.

Build quality and mounting implications

Festo construction gives consistent sealing and low friction over the short stroke. The compact body allows direct mounting on machine frames or fixture plates where space is limited. Red finish aids visual identification during maintenance checks.

Highlights

  • 32 mm bore fits tight machine spaces
  • 10 mm stroke enables precise short movements
  • Compact design reduces overall assembly footprint
  • Festo 536269 part ensures correct replacement identification
  • Red finish allows quick visual identification in systems

Specifications

BrandFESTO
ModelADN-32-10-A-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Should I choose the 32 mm bore with 10 mm stroke or a different size for my application?

The ADN-32-10-A-P-A has a 32 mm bore and 10 mm stroke; select this version when those exact dimensions match your mounting and force requirements.

What does the 10 mm stroke mean once the cylinder is installed in a machine?

The piston travels 10 mm from fully retracted to fully extended, giving a short, precise linear motion for clamping or positioning tasks.

Which pneumatic interface does the ADN-32-10-A-P-A use and what does it limit in practice?

It uses standard G1/8 ports, so flow and pressure are limited by the fitting and tubing size you connect to those ports.
