Red compact air cylinder, model ADN-20-60-A-P

Festo

Festo ADN-20-60-A-P 20 60 Compact Air Cylinder

SKU CH-GKFK-CWDER MPN ADN-20-60-A-P

Compact air cylinder with a 20 mm bore and 60 mm stroke for pneumatic automation tasks

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact air cylinder saves installation space with 20 mm bore
  • 60 mm stroke provides precise linear motion control
  • Festo engineering ensures reliable pneumatic performance
  • Red finish allows quick visual identification in systems
  • Supplied as single unit in box for immediate use

Compact Air Cylinder for Automation

The Festo ADN-20-60-A-P is a compact pneumatic cylinder designed for machine builders and maintenance engineers who need reliable linear motion in tight spaces. It delivers a 20 mm bore and 60 mm stroke in a single unit. The red finish aids quick identification during installation or inspection.

Practical Limits of Pneumatic Actuation

This cylinder operates on compressed air, so its force and speed depend entirely on the supply pressure and flow available at the point of use. It cannot generate motion without a prepared pneumatic circuit, suitable fittings and adequate filtration. The compact body restricts mounting options to those compatible with its specific footprint.

Replacing Larger Tie-Rod Cylinders

This model replaces bulkier tie-rod cylinders where space is constrained and the required force falls within the 20 mm bore capacity. The jump is worth it when a machine layout demands a shorter overall length and simpler mounting without sacrificing the stroke length needed for the application. Part number 536352 confirms the exact specification.

Highlights

  • Compact air cylinder saves installation space with 20 mm bore
  • 60 mm stroke provides precise linear motion control
  • Festo engineering ensures reliable pneumatic performance
  • Red finish allows quick visual identification in systems
  • Supplied as single unit in box for immediate use

Specifications

BrandFESTO
ModelADN-20-60-A-P
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Should I pick the 20 mm bore or the 60 mm stroke version of the ADN-20-60-A-P?

The model number ADN-20-60-A-P identifies a single cylinder with a 20 mm bore and a 60 mm stroke; there is no separate bore-only or stroke-only variant to choose.

What does the 60 mm stroke mean when the cylinder is installed in a machine?

The piston travels 60 mm between its fully retracted and fully extended positions, giving that linear working distance in the application.

Which pneumatic interface does the ADN-20-60-A-P use and what does it limit?

The cylinder connects via standard G 1/8 ports, so flow and pressure are limited by the fitting and tubing size used with that thread.
