Red Festo compact air cylinder model ADN-16-5-A-P-A in box

Festo

Festo ADN-16-5-A-P-A 536219 Compact Air Cylinder

SKU CH-WZ6J-1TQ1G MPN ADN-16-5-A-P-A

Compact air cylinder with 16 mm bore delivers reliable pneumatic force in tight spaces

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 16 mm bore suits tight installations
  • 536219 model ensures exact replacement fit
  • Festo engineering delivers reliable pneumatic actuation
  • Red finish provides clear visual identification
  • Supplied as single unit in protective box

Compact Air Cylinder 16mm Bore

The Festo ADN-16-5-A-P-A is a compact air cylinder designed for pneumatic automation tasks. It suits engineers and technicians who need reliable linear motion in space-constrained installations. The unit arrives new in a single pack, ready for integration into existing compressed-air systems.

Installation and Common Issues

Mounting uses standard Festo patterns, so alignment with existing brackets is straightforward. The main difficulty is ensuring clean, dry compressed air; contaminated supply causes premature seal wear and erratic stroke behaviour. Proper torque on fittings prevents air leaks at the ports.

Pre-Order Checks

Verify that your system operates within the cylinder's pressure range and that the 16mm bore matches the required force output. Confirm the mounting style and port thread type match your current manifold or valve block. Ensure the actuator's stroke length fits the available mechanical travel in your application.

Highlights

  • Compact 16 mm bore suits tight installations
  • 536219 model ensures exact replacement fit
  • Festo engineering delivers reliable pneumatic actuation
  • Red finish provides clear visual identification
  • Supplied as single unit in protective box

Specifications

BrandFESTO
ModelADN-16-5-A-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How can I verify the ADN-16-5-A-P-A is cycling correctly after installation?

Pressurise the cylinder and confirm the piston extends and retracts smoothly over the full 16 mm stroke without binding or air leaks.

What comes in the box with the ADN-16-5-A-P-A and what must I source separately?

The box contains one new compact air cylinder, model 536219; fittings, tubing and mounting hardware are not included.

Which version of the ADN compact cylinder should I choose for a 16 mm bore requirement?

Select the ADN-16-5-A-P-A variant, which is built for a 16 mm bore and carries part number 536219.
