Red compact air cylinder, model ADN-12-25-I-P-A

Festo

Festo ADN-12-25-I-P-A 536215 Compact Air Cylinder

SKU CH-E7CD-QS9WH MPN ADN-12-25-I-P-A

Compact air cylinder with 12 mm bore and 25 mm stroke for pneumatic automation

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 12 mm bore fits tight machine spaces
  • 25 mm stroke delivers precise short linear motion
  • Festo 536215 model ensures reliable pneumatic performance
  • Red finish allows quick visual identification on assemblies
  • Supplied as single unit in box for immediate installation

Product identity and intended use

The Festo ADN-12-25-I-P-A 536215 is a compact air cylinder designed for pneumatic automation tasks. It suits engineers and technicians who need reliable linear motion in space-constrained installations. The unit is supplied new in a single pack. Buyers requiring hydraulic actuation or electric linear drives should consider alternative technologies.

Capacity and operational headroom

The cylinder provides a 12 mm bore with a 25 mm stroke, delivering precise short-travel movement for clamping, positioning or ejecting duties. It handles repetitive cycles within its rated pressure range but reaches its mechanical limit at the specified stroke length. Applications demanding longer travel or higher force output will exceed the design envelope.

Thermals noise and power consumption

Compressed-air operation keeps the body cool during continuous cycling, with no motor heat to dissipate. Noise levels are limited to the exhaust note of the control valve and the cylinder’s end-of-stroke cushioning. Power draw is determined solely by the upstream compressor and valve selection, not by the cylinder itself.

Highlights

  • Compact 12 mm bore fits tight machine spaces
  • 25 mm stroke delivers precise short linear motion
  • Festo 536215 model ensures reliable pneumatic performance
  • Red finish allows quick visual identification on assemblies
  • Supplied as single unit in box for immediate installation

Specifications

BrandFESTO
ModelADN-12-25-I-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Will the ADN-12-25-I-P-A cylinder mount directly to my existing Festo 12 mm bore brackets?

Yes, the 12 mm bore matches standard Festo mounting patterns for that size, so your current brackets should align without adapters.

How can I verify the ADN-12-25-I-P-A is cycling correctly after installation?

Pressurise the port and confirm smooth 25 mm stroke travel with no binding; the piston should extend and retract cleanly at your regulated pressure.

Does the box for part 536215 include fittings and tubing or just the cylinder?

The pack contains one compact air cylinder only; pneumatic fittings, tubing and flow controls must be purchased separately.
