Red compact air cylinder, metal body, threaded ports

Festo

Festo ADN-100-80-I-P-A 536392 Compact Air Cylinder

SKU CH-0MCV-1V0TT MPN ADN-100-80-I-P-A

Compact air cylinder with 100 mm bore and 80 mm stroke, supplied as a single unit in a box

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 100 mm bore cylinder fits tight machine spaces
  • 80 mm stroke delivers precise linear motion
  • Festo 536392 model ensures pneumatic system compatibility
  • Red finish allows quick visual identification in assemblies
  • Supplied as single unit in box for immediate installation

Compact pneumatic actuator for automation tasks

The Festo ADN-100-80-I-P-A is a compact air cylinder designed for linear motion in automated machinery. Its 100 mm bore and 80 mm stroke suit medium-force applications where installation space is limited. The unit arrives new in a single pack, ready for integration into pneumatic systems.

Suited for machine builders needing a space-saving

Engineers specifying new actuators for pick-and-place, clamping or pressing stations will match the bore and stroke to their design calculations. Maintenance teams replacing a worn unit with the same part number 536392 avoid re-engineering brackets or plumbing. Buyers who need a different stroke length, bore size or mounting style must select another variant.

Bore 100 mm and stroke 80 mm define fit and force

These two dimensions determine the cylinder's theoretical force output at a given pressure and the physical envelope it occupies. Verifying both values against the mechanical layout confirms whether this specific model satisfies the application requirements.

Highlights

  • Compact 100 mm bore cylinder fits tight machine spaces
  • 80 mm stroke delivers precise linear motion
  • Festo 536392 model ensures pneumatic system compatibility
  • Red finish allows quick visual identification in assemblies
  • Supplied as single unit in box for immediate installation

Specifications

BrandFESTO
ModelADN-100-80-I-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What bore and stroke dimensions determine if the ADN-100-80-I-P-A fits my machine?

The cylinder has a 100 mm bore and 80 mm stroke, so check your mounting envelope against those figures before ordering.

Which ports and mounting threads must I prepare for installing the ADN-100-80-I-P-A?

Use the standard pneumatic ports on the end caps and the threaded mounting holes on the body; the common mistake is forgetting to apply thread sealant on the port fittings.

When should I replace the piston seals on the ADN-100-80-I-P-A?

Plan to inspect and replace the piston seals after roughly three years of regular cycling, which matches the parts coverage period.
