Red compact air cylinder, 100mm bore, 60mm stroke

Festo

Festo ADN-100-60-A-P-A 100mm 60mm stroke compact air cylinder

SKU CH-G7S1-4EHGG MPN ADN-100-60-A-P-A

Compact air cylinder with a 100 mm bore and 60 mm stroke for pneumatic automation

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 100 mm bore delivers strong force for heavy-duty clamping
  • 60 mm stroke provides precise linear travel in tight spaces
  • Compact design fits inside narrow machine frames
  • Festo engineering ensures repeatable motion cycle after cycle
  • Red finish allows quick visual identification on the line

Compact air cylinder for automation tasks

The Festo ADN-100-60-A-P-A is a compact air cylinder built for linear motion in machine automation. It suits engineers and technicians who need reliable actuation in limited space. The unit arrives new and ready for integration into pneumatic systems.

Replaces worn cylinders in existing setups

This model replaces damaged or ageing cylinders with the same 100mm bore and 60mm stroke dimensions. The jump is worth it when seal wear or rod scoring causes inconsistent travel or air leakage. Matching the original specifications restores repeatable performance without redesign.

Simple mounting with standard pneumatic practice

Installation follows standard pneumatic practice using the cylinder's existing mounting interfaces and port connections. Common issues include misaligned loads that side-load the piston rod and contaminated air supply that accelerates seal wear. Proper filtration and alignment prevent premature failure.

Highlights

  • 100 mm bore delivers strong force for heavy-duty clamping
  • 60 mm stroke provides precise linear travel in tight spaces
  • Compact design fits inside narrow machine frames
  • Festo engineering ensures repeatable motion cycle after cycle
  • Red finish allows quick visual identification on the line

Specifications

BrandFESTO
ModelADN-100-60-A-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What mounting pattern and bore size does the ADN-100-60-A-P-A cylinder require?

The cylinder uses a 100 mm bore and standard ISO mounting holes; verify the pattern on the Festo 536381 datasheet before drilling.

Which step is often missed when fitting the ADN-100-60-A-P-A cylinder?

Many installers forget to apply thread sealant to the supply ports and to torque the mounting bolts to the Festo specification.

When should the piston seal on the ADN-100-60-A-P-A be replaced?

Festo rates the seal kit for three years of normal cycling; plan replacement at that interval or if leakage appears.
