Red compact air cylinder, 100mm bore, 10mm stroke

Festo

Festo ADN-100-10-A-P-A 100mm 10mm stroke compact air cylinder

SKU CH-ZRH5-KMKV0 MPN ADN-100-10-A-P-A

Compact air cylinder with 100 mm bore and 10 mm stroke for precise linear motion

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 100 mm bore delivers strong linear force
  • 10 mm stroke enables precise short movements
  • Compact design fits tight machine spaces
  • New condition ensures full factory performance
  • Manufacturer part 536374 simplifies ordering and replacement

Compact cylinder for pneumatic automation

The Festo ADN-100-10-A-P-A is a compact air cylinder with a 100 mm bore and 10 mm stroke. It suits machine builders and maintenance teams who need short linear motion in tight spaces. The unit is supplied new in a single pack identified by part number 536374. Its red finish helps quick visual identification on assembly lines.

Low friction operation with minimal air consumption

The short stroke limits the air volume required for each cycle, reducing compressor demand during normal use. Smooth internal surfaces keep friction low so the cylinder runs quietly without added lubrication. Heat build-up stays negligible because the moving mass is small and the duty cycle is typically intermittent. No external cooling or noise attenuation is required.

Ready to mount with standard accessories

The cylinder ships in a box as a complete unit, so installers can bolt it directly to existing mounting patterns. A three-year parts guarantee and one-year labour cover protect against early wear in continuous cycling applications. No separate sensor, tubing or fittings are included, allowing users to select components that match their control system.

Highlights

  • 100 mm bore delivers strong linear force
  • 10 mm stroke enables precise short movements
  • Compact design fits tight machine spaces
  • New condition ensures full factory performance
  • Manufacturer part 536374 simplifies ordering and replacement

Specifications

BrandFESTO
ModelADN-100-10-A-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How do I mount the ADN-100-10-A-P-A and what alignment mistake should I avoid?

Use the standard mounting holes on the 100 mm body; the step often missed is ensuring the load is perfectly axial so the 10 mm stroke operates without side loading.

Which seals will need replacement on the ADN-100-10-A-P-A after extended use?

The piston and rod seals are the main wear items; inspect them during scheduled downtime and replace as a kit when leakage or reduced force appears.

What is the first limitation of the ADN-100-10-A-P-A during continuous cycling?

The 10 mm stroke length limits total travel per cycle, so high-frequency applications reach the mechanical end-stops faster than longer-stroke alternatives.
