FASCO D742 condenser fan motor steel open frame

FASCO

FASCO D742 1/4 HP 208-230V Condenser Fan Motor

SKU CH-DG8Q-SW1GX

A 1/4 HP condenser fan motor running at 1075 RPM on 208-230V AC with reversible rotation and automatic thermal protection

  • MaterialHAWA
  • 1/4 HP permanent-split-capacitor motor delivers 190 W continuous output
  • Auto thermal protection and Class B insulation rated for 40 °C ambient
  • Reversible CW/CCW rotation suits either airflow direction
  • 208–230 V single-phase, 60 Hz with 2.1 A full-load current
  • Open driproof steel frame in 48 frame size with stud mounting

What this motor is and who it fits

The FASCO D742 is a new condenser fan motor rated at 1/4 HP for 208-230V AC single-phase supplies. It uses a permanent split capacitor design and a 48 frame steel housing with stud mounting. The open dripproof enclosure suits continuous duty in HVAC condenser units where a direct replacement match is required.

The spec that decides fit

Nameplate speed is 1,075 RPM at 60 Hz with a 1.0 service factor and Class B insulation. Full-load current is 2.1 A at 230 V and the motor is usable at 208 V but not at 200 V. Rotation is reversible CW/CCW and thermal protection is automatic, so the electrical nameplate must match the original unit exactly.

Heat, noise and power in normal use

Output is 190 W continuous with a maximum ambient temperature of 40 °C. The open dripproof steel frame relies on natural airflow through the condenser for cooling. Auto-reset thermal protection cuts power if internal temperature exceeds the Class B limit, then restarts once the motor cools.

Highlights

  • 1/4 HP permanent-split-capacitor motor delivers 190 W continuous output
  • Auto thermal protection and Class B insulation rated for 40 °C ambient
  • Reversible CW/CCW rotation suits either airflow direction
  • 208–230 V single-phase, 60 Hz with 2.1 A full-load current
  • Open driproof steel frame in 48 frame size with stud mounting

Specifications

BrandFASCO
MaterialHAWA

Questions about this item

What does the 1075 RPM rating mean once the motor is installed in a condenser unit?

The motor runs at 1075 RPM under full load, delivering 190 W of mechanical output to drive the condenser fan blade at its design speed.

How does the 208-230 V single-phase supply and 2.1 A full-load current limit what the motor can do?

It draws 2.1 A at 208-230 V AC, 60 Hz, and is rated for continuous duty at up to 40 °C ambient; operation at 200 V is not supported.

What does the 48 frame and stud mounting require for physical installation?

The steel 48-frame body uses stud mounting, so the replacement must match the same bolt pattern and shaft dimensions to fit the existing bracket.
