ebmpapst A4D300-AS34-02 axial fan with metal housing and exposed blades

Fans

Fans A4D300-AS34-02 Axial Flow Fan 230V 0.40A 400W

SKU CH-SX0P-A38JG

An axial flow fan for industrial cooling, running on 230 V at 0.40 A with CE approval

  • Reliable cooling from -25 °C to 60 °C ambient range
  • Low 68 W draw at 50 Hz for energy savings
  • Compact external-rotor design fits tight enclosures
  • CE-approved safety for industrial installations
  • Airflow up to 35000 m³/h for high-capacity heat exchange

Product Identity

This is an original ebmpapst A4D300-AS34-02 axial flow fan rated for 230V single-phase supply with a 0.40A nameplate current and 400W motor rating. It suits industrial cooling systems that need high-volume airflow in a compact housing.

Upgrade Context

The fan replaces older belt-driven or larger-frame axial units where space depth is limited and noise must stay low. The jump is worth it when the installation can accept a 400V three-phase winding wired in Y configuration and the application runs at either 50Hz or 60Hz mains frequency.

Pre-Order Checklist

Verify that your supply delivers 400V three-phase Y-wired power and that the control circuit can provide 0-10V or serial speed reference for the EC motor. Confirm the operating ambient range of -25°C to 60°C covers the site conditions and that the maximum back-pressure of 60-70Pa matches the duct resistance.

Highlights

  • Reliable cooling from -25 °C to 60 °C ambient range
  • Low 68 W draw at 50 Hz for energy savings
  • Compact external-rotor design fits tight enclosures
  • CE-approved safety for industrial installations
  • Airflow up to 35000 m³/h for high-capacity heat exchange

Specifications

No published specifications for this item yet.

Questions about this item

What mounting depth does the A4D300-AS34-02 axial fan require?

The fan uses a compact external-rotor motor design that minimises installation depth, making it suitable for tight enclosures and heat-exchanger arrays.

How is the three-phase 400 VAC supply wired for the A4D300-AS34-02?

Connect the supply in a Y (star) configuration to the three-phase terminals; the fan runs at 50 Hz (1300 rpm, 68 W, 0.14 A) or 60 Hz (1400 rpm, 90 W, 0.15 A).

What is the expected bearing life at the maximum 60 °C ambient rating?

The fan is rated for continuous operation up to 60 °C at 50 Hz; plan bearing inspection or replacement once the unit approaches its design life under sustained high-temperature running.
