Black extended push button with metal bezel and screw terminals

Eaton

Eaton 10250T708B Extended Push Button Disconnect, Black

SKU CH-TMTM-P9T8R

A 30 mm hazardous-location push button with 1 NC and 1 NO contacts rated 10A at 600V AC and 2.5A at 250V DC, NEMA 12, 13, 3, 3R, 4, 4X and IP65 rated

  • MaterialHAWA
  • Momentary action enables precise control
  • Extended metal head provides reliable operation
  • 1 NO + 1 NC contacts support versatile wiring
  • IP65 and NEMA 4X ratings suit harsh environments
  • Rated 10A at 600V AC for industrial circuits

Industrial Push-Button Disconnect

The Eaton 10250T708B is a 30 mm extended push-button disconnect designed for hazardous-location machinery control. It provides momentary action with one normally closed and one normally open contact, suited for maintenance panels and safety circuits.

Metal Head and Screw-Clamp Terminals

The operator head and bezel are metal, rated NEMA 12, 13, 3, 3R, 4, 4X and IP65 for dust, water and oil resistance. Screw-clamp terminals accept ring or fork lugs for secure wiring in vibration-prone enclosures.

10 A at 600 V AC Contact Rating

The contacts carry 10 A at 600 V AC and 2.5 A at 250 V DC under NEMA A600 and Q300 designations. This rating determines whether the switch can handle the control-circuit load in your application.

Highlights

  • Momentary action enables precise control
  • Extended metal head provides reliable operation
  • 1 NO + 1 NC contacts support versatile wiring
  • IP65 and NEMA 4X ratings suit harsh environments
  • Rated 10A at 600V AC for industrial circuits

Specifications

MaterialHAWA
BrandEATON

Questions about this item

What contact ratings does the 10250T708B push button support?

It is rated for 10 A at 600 V AC and 2.5 A at 250 V DC, with NEMA designations A600 and Q300.

What panel cut-out and bezel style does this operator need?

The unit fits a 30 mm panel cut-out and uses a metal bezel for secure mounting.

How are the wires terminated on the contacts, and what mistake should be avoided?

Connections use screw-clamp terminals; the common error is leaving screws loose, which causes intermittent contact.
