White-lit 52mm fuel gauge with E-1/2-F dial and sender kit

Dyno Racing

Dyno Racing Fuel Level Gauge 52mm 12V White Light E-1/2-F

SKU CH-NDYH-1FQC2

A 52 mm fuel-level gauge with white illumination and matching sender, calibrated E-1/2-F for 12 V vehicles

  • TypeGauges
  • Gauge TypeFuel Pressure
  • White-lit dial for clear night reading
  • 52 mm diameter fits standard gauge pods
  • Resistance scale E-1/2-F matches 220/98.5/33.5 ohm senders
  • Includes transmitter and float for complete installation
  • 12 V power suits most vehicle electrical systems

Universal Fuel Level Gauge

This 52mm diameter gauge measures fuel level in most 12 Volt cars. It reads E-1/2-F with a white illuminated display for clear visibility. The kit includes a fuel level transmitter, oil float, rubber pad, bolts and instructions. Professional installation is recommended for reliable operation.

Resistance Range and Fitment

The sender operates at three fixed resistance points: 220 ohms at empty, 98.5 ohms at half and 33.5 ohms at full. Your vehicle's existing sender must match these values or the gauge will read incorrectly. The gauge requires a 52mm cut-out; the visible screen area is 43mm inside diameter and 56mm outside diameter.

Pre-Installation Checks

Confirm your car runs a 12 Volt electrical system before ordering. Verify the original fuel sender resistance curve matches the 220, 98.5 and 33.5 ohm points listed. Ensure the dashboard opening can accommodate a 52mm gauge with a 56mm outer bezel. Check that wiring length reaches the rear sender location.

Highlights

  • White-lit dial for clear night reading
  • 52 mm diameter fits standard gauge pods
  • Resistance scale E-1/2-F matches 220/98.5/33.5 ohm senders
  • Includes transmitter and float for complete installation
  • 12 V power suits most vehicle electrical systems

Specifications

TypeGauges
Gauge TypeFuel Pressure

Questions about this item

Which version of the Dyno Racing fuel gauge should I choose for a standard 12 V car?

The gauge is supplied as a single 52 mm diameter unit with white lighting and an E-1/2-F scale; it includes the transmitter, float, rubber pad, bolts and instructions, so no other version or capacity options exist for this listing.

What does the E-1/2-F reading actually show once the gauge is installed?

The pointer indicates tank level using three reference resistances: 220 ohms at empty, 98.5 ohms at half and 33.5 ohms at full, giving a clear visual of remaining fuel.

What interface does the gauge use and what does that limit in practice?

It connects to the included fuel-level transmitter via a resistive sender circuit calibrated to 12 V systems, so the reading is capped by the 220-ohm-to-33.5-ohm range the transmitter provides.
