Powder-coated steel H-bracket with U-mount arms and slotted adjustment holes

Diversitech Corp.

Diversitech Corp. QUICK-SLING QSWI1000 Mounting Bracket 200 lbs U-Mount H-Bracket pneumatic components power

SKU CH-MK8K-D4799

A 200 lb capacity mounting bracket with slotted holes for width adjustment and a swivel spreader arm with circular adjustment plate

  • Supports heavy equipment up to 200 lbs with robust U-Mount H-Bracket design
  • Powder-coated finish resists corrosion for long-lasting durability in demanding environments
  • Slotted holes provide flexible width adjustment for precise installation alignment
  • Swivel spreader arm with circular adjustment plate enables versatile positioning options
  • Includes complete hardware kit with swivel bolt, lock nut, cotter pin, thumb screw, washers, and wing nut

Quick-Sling QSWI1000 Mounting Bracket

The Quick-Sling QSWI1000 is a powder-coated steel mounting bracket rated for 200 lbs. It is designed to secure air handlers, furnaces and unit heaters in commercial or residential mechanical rooms. The kit includes a U-bar, H-bracket, left and right arms, and all necessary hardware for installation.

Suitable Installations And Limits

This bracket suits installers who need a four-point contact mount with slotted holes for width adjustment and a swivel spreader arm with a circular adjustment plate. It is not for buyers who need a higher load rating than 200 lbs or a different mounting geometry than the U-mount H-bracket style.

Critical Dimensions For Fit

The overall dimensions are 29 11/16 in height, 20 3/4 in width and 24 5/8 in depth. Verify these measurements against the equipment footprint and available clearance before purchase to ensure proper fit.

Highlights

  • Supports heavy equipment up to 200 lbs with robust U-Mount H-Bracket design
  • Powder-coated finish resists corrosion for long-lasting durability in demanding environments
  • Slotted holes provide flexible width adjustment for precise installation alignment
  • Swivel spreader arm with circular adjustment plate enables versatile positioning options
  • Includes complete hardware kit with swivel bolt, lock nut, cotter pin, thumb screw, washers, and wing nut

Specifications

BrandQUICK-SLING

Questions about this item

How much weight does the 200 lbs rating actually support when the bracket is mounted on a unit heater?

The bracket is rated for 200 lbs and is compatible with unit heaters, furnaces and air handlers, so that figure represents the maximum load it can carry in those installations.

What does the U-Mount H-Bracket design mean for how the bracket attaches to the equipment?

It uses a U-bar with a circular adjustment plate, slotted holes for width adjustment, a swivel spreader arm and thumb screw to secure the unit at four contact points.

Will the 29 11/16 in overall height and 24 5/8 in depth fit inside a standard furnace cabinet?

The bracket measures 29 11/16 in tall, 20 3/4 in wide and 24 5/8 in deep, so you need a cabinet opening that exceeds those dimensions for clearance.
