Dayton 1 hp split-phase blower motor, rolled steel frame, Dayton Gray finish

Dayton

Dayton 1YBV1 Split-Phase Blower 1 hp 1725 rpm

SKU CH-KFT0-N24E2

Split-phase agricultural blower motor delivers 1 hp at 1725 rpm with dual-voltage 115/230 V operation and continuous duty rating

  • 1 hp split-phase motor delivers strong airflow for agricultural ventilation
  • 1725 rpm nameplate speed provides consistent single-speed operation
  • Dual 115/230 V AC input suits standard and higher-voltage farm circuits
  • Totally enclosed air-over enclosure protects windings from dust and moisture
  • Auto thermal protection and 1.25 service factor extend motor life under continuous duty

Dayton 1 hp Split-Phase Blower

The Dayton 1YBV1 is a 1 hp split-phase blower motor built for continuous-duty air-moving tasks in HVAC and agricultural settings. Its totally enclosed air-over enclosure and rigid-base mounting suit indoor or sheltered installations where reliable, single-speed airflow is required.

115/230 V Single-Phase Operation

The motor runs on 115 V or 230 V single-phase supply at 60 Hz, drawing 13.0 A at low voltage or 6.5 A at high voltage. Auto-reset thermal protection and Class B insulation limit the maximum ambient temperature to 40 °C, so the unit must operate within that thermal envelope.

1 hp Continuous-Duty Capacity

Rated at 1 hp with a 1.25 service factor, the motor delivers 1725 rpm nameplate speed under full load. It handles steady airflow duties within its voltage and temperature limits, but provides no variable-speed control and cannot exceed its single-speed, continuous-duty design envelope.

Highlights

  • 1 hp split-phase motor delivers strong airflow for agricultural ventilation
  • 1725 rpm nameplate speed provides consistent single-speed operation
  • Dual 115/230 V AC input suits standard and higher-voltage farm circuits
  • Totally enclosed air-over enclosure protects windings from dust and moisture
  • Auto thermal protection and 1.25 service factor extend motor life under continuous duty

Specifications

BrandDAYTON

Questions about this item

Should I wire this 1 hp split-phase blower for 115 V or 230 V?

The motor accepts both 115 V and 230 V AC; at 115 V it draws 13.0 A full load, at 230 V it draws 6.5 A.

What does the 1725 rpm nameplate speed mean once the blower is installed?

Under full load the shaft turns at 1,725 rpm on 60 Hz supply, delivering the rated 1 hp output.

How does the split-phase design and 56 frame affect what I can connect?

Split-phase operation provides single-phase starting torque, and the NEMA 56 frame with rigid base fits standard 56-frame mounting patterns.
