Rectangular silver industrial cooling fan 172 by 150 by 55 mm with metal frame and mounting holes

Corn Electronics

Corn Electronics UT655D-TP industrial cooling fan 172×150×55mm 200VAC 43/40W

SKU CH-ECB0-1M5SY MPN UT655D-TP

200 VAC industrial cooling fan measuring 172 × 150 × 55 mm with 162 mm hole spacing, delivering 5.2 to 6.0 m³/min airflow at 2800 to 3250 RPM and 43/40 W power draw

  • Delivers 5.2 m³/min airflow at 50 Hz for effective heat removal
  • Runs on 200 VAC 50/60 Hz supply compatible with industrial inverters
  • Operates at 55 dB(A) low speed for quieter cabinet environments
  • Mounts using 162 mm hole spacing for standard panel cut-outs
  • Weighs 1.2 kg for secure yet manageable installation

Industrial 200 VAC cooling fan for Fanuc spindle

The Corn Electronics UT655D-TP is a new industrial cooling fan built to 172×150×55 mm dimensions with 162 mm hole spacing. It runs on 200 VAC at 50/60 Hz and draws 43 W at 50 Hz or 40 W at 60 Hz. The unit weighs 1.2 kg and is designed as a direct replacement for Fanuc robotics spindle motor covers.

Suits maintenance teams repairing Fanuc spindle

Technicians who need a drop-in fan with the exact 172×55 mm frame, 162 mm mounting pattern and 200 VAC rating will find this part matches the original specification. Buyers who require a different voltage, a smaller frame size or a lower noise rating should look at other models because this unit is fixed at 55/58 dB(A) and the stated physical envelope.

200 VAC 50/60 Hz voltage rating decides fit

The fan only operates on a 200 VAC supply at 50/60 Hz; connecting it to any other mains voltage will damage the motor. Confirm the equipment nameplate shows 200 VAC before ordering.

Highlights

  • Delivers 5.2 m³/min airflow at 50 Hz for effective heat removal
  • Runs on 200 VAC 50/60 Hz supply compatible with industrial inverters
  • Operates at 55 dB(A) low speed for quieter cabinet environments
  • Mounts using 162 mm hole spacing for standard panel cut-outs
  • Weighs 1.2 kg for secure yet manageable installation

Specifications

BrandRoyal Fan
ModelUT655D-TP

Questions about this item

Will the 162 mm hole spacing match the mounting pattern on my existing Fanuc spindle motor cover?

Yes, the fan uses a 162 mm hole spacing designed for Fanuc robotics spindle motor covers.

What RPM and noise values should I expect once the fan is powered at 200 VAC 50/60 Hz?

At 50 Hz it runs at 2800 RPM with 55 dB(A); at 60 Hz it reaches 3250 RPM and 58 dB(A).

Does the box include mounting screws or a power cable, or must I source them separately?

The package contains only the fan unit weighing 1.2 kg; screws and wiring are not included.
