Red CKD double-acting wide parallel hand cylinder in box

CKD

CKD HFP-3CS-T3H-D Cylinder Double Acting Wide Parallel Hand electrician tool

SKU CH-1YMX-R50HR MPN HFP-3CS-T3H-D

Double-acting wide parallel hand cylinder for pneumatic gripping tasks, supplied new in a single pack with a red finish

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Double-acting cylinder delivers force in both directions
  • Wide parallel hand design enables secure gripping of larger workpieces
  • Red finish provides high visibility in workshop environments
  • Three-year parts coverage supports long-term reliability
  • Supplied as a single unit in protective box packaging

Product Identity

The CKD HFP-3CS-T3H-D is a double-acting wide parallel hand cylinder designed for pneumatic automation. It provides linear motion with synchronised opposing jaws for gripping or positioning tasks in industrial settings. Supplied new in a single pack, it carries a three-year parts and one-year labour warranty.

Suitability

This cylinder suits machine builders and maintenance engineers who need a compact, wide-opening parallel gripper for pick-and-place or assembly stations. It is not intended for applications requiring high-force angular grippers, rotary actuators, or electric servo-driven motion profiles.

Capacity and Limits

The double-acting design delivers consistent clamping force in both directions across the full stroke range. Headroom is defined by the bore and pressure rating inherent to the HFP-3CS series; exceeding the rated operating pressure or lateral load limits will reduce service life and repeatability.

Highlights

  • Double-acting cylinder delivers force in both directions
  • Wide parallel hand design enables secure gripping of larger workpieces
  • Red finish provides high visibility in workshop environments
  • Three-year parts coverage supports long-term reliability
  • Supplied as a single unit in protective box packaging

Specifications

BrandCKD
ModelHFP-3CS-T3H-D
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Does the HFP-3CS-T3H-D cylinder need a specific compressed-air supply to operate?

Yes, it is a double-acting pneumatic cylinder, so you must supply clean, dry compressed air to both ports and have a suitable valve and tubing kit ready before installation.

Can I keep my existing pneumatic tubing and fittings when fitting this wide parallel hand cylinder?

The cylinder uses standard pneumatic ports, so your current tubing and fittings will connect directly as long as they match the port thread size and pressure rating.

How can I verify the HFP-3CS-T3H-D is working correctly after I pipe it up?

Apply air pressure and confirm the jaws open and close smoothly in both directions without sticking, then check for leaks at the ports and seals using soapy water.
