Red metal pilot-operated five-way pneumatic valve with 24V DC solenoid

CKD

CKD 4F620-20-L-DC24V Pilot Operated Five-Way Valve

SKU CH-RD9G-D8RCX

Pilot-operated five-way pneumatic valve with 24 V DC actuation for directional airflow control

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Pilot operated design ensures reliable pneumatic switching
  • Five-way valve configuration enables complex flow control
  • DC 24 V coil voltage suits standard automation systems
  • Model 4F620-20-L built for industrial durability
  • Red finish provides clear visual identification

Pilot Operated Five-Way Valve

The CKD 4F620-20-L-DC24V is a pilot operated five-way pneumatic valve designed for controlling compressed air flow in automated systems. It operates on a 24V DC supply and suits engineers integrating directional control into machinery. The unit is supplied new in a single pack box with a red finish.

Verify Voltage And Port Requirements

Confirm that your control circuit provides a stable 24V DC source matching the coil rating before installation. Check that the existing manifold or piping uses compatible port sizes for the 620 series interface. Ensure the pneumatic supply pressure falls within the valve's rated operating range for pilot operation.

Integrates Into Pneumatic Circuits

This valve directs air to double-acting cylinders or other actuators requiring five-port switching logic. The pilot operated design reduces the electrical power needed for shifting compared to direct-acting alternatives. It frees up control panel space by using a compact body while the three-year parts coverage supports long-term maintenance planning.

Highlights

  • Pilot operated design ensures reliable pneumatic switching
  • Five-way valve configuration enables complex flow control
  • DC 24 V coil voltage suits standard automation systems
  • Model 4F620-20-L built for industrial durability
  • Red finish provides clear visual identification

Specifications

BrandCKD
ModelCKD 4F620-20-L-DC24V
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Does the CKD 4F620-20-L-DC24V valve ship as a single unit or in a multi-pack?

The valve is supplied as one unit per box, with an item count of one pack.

What does the 24 V DC rating on the 4F620-20-L model indicate for installation?

It shows the solenoid coil requires a 24 V DC power supply to actuate the pilot-operated five-way valve.

How does the 620 series designation relate to the valve's function in a pneumatic circuit?

The 620 series identifies this CKD model as a pilot-operated five-way valve designed for directional control in pneumatic systems.
