Rectangular black battery pack with wire connector, 125 by 64.8 by 13.92 millimetres

Cameron Sino EZ500 7200mAh 53.28Wh battery

SKU CH-C30D-M01JS MPN EZ500

Replacement battery for XTOOL diagnostic scanners, 7200mAh 53.28Wh at 7.4V with built-in protection circuits

  • Extended runtime for diagnostic scanners with 7200mAh capacity
  • Direct replacement for XTOOL EZ500, i80 Pad, PS80 series and X100 Pad 2 models
  • Certified safety with ISO9001, RoHS and CE compliance
  • Built-in protection against overcharge, over-discharge and short circuits
  • Compact 125.10 x 64.80 x 13.92mm design fits original battery bay

Replacement Battery for XTOOL Scanners

The Cameron Sino EZ500 battery is a direct replacement for XTOOL diagnostic scanners including the EZ500, i80 Pad, PS80, PS80E, X100 Pad 2, X100 Pad 2 Pro and X7. It delivers 7200mAh capacity at 7.4V for 53.28Wh total energy. A fully decoded chip ensures communication with the tool matches the original equipment. The pack measures 125.10 x 64.80 x 13.92mm and weighs 270.2g.

Upgrade From Depleted Original Cells

This unit replaces a factory battery that no longer holds sufficient charge for a full workday. The jump is worth it when the scanner shuts down mid-diagnosis or requires constant tethering to a charger. Fresh cells restore the rated 7200mAh capacity and the protection circuit guards against overcharge, over-discharge, over-voltage and short circuits. Performance peaks after two or three complete charge and discharge cycles.

Verify Model and Part Number First

Confirm the scanner model name and the original battery part number PL3769124 2S before ordering. Ensure the connector aligns correctly during installation. Do not use low-quality third-party chargers as they reduce service life. Avoid storage above 60°C (140°F) and never disassemble or expose the pack to fire or water.

Highlights

  • Extended runtime for diagnostic scanners with 7200mAh capacity
  • Direct replacement for XTOOL EZ500, i80 Pad, PS80 series and X100 Pad 2 models
  • Certified safety with ISO9001, RoHS and CE compliance
  • Built-in protection against overcharge, over-discharge and short circuits
  • Compact 125.10 x 64.80 x 13.92mm design fits original battery bay

Specifications

Brandcameron sino
ModelEZ500, i80 Pad, PS80, PS80E, PS90, PS90HD, PS90Pro Diagnostic Scan Tools, X7
Part NumberPL3769124 2S

Questions about this item

What are the exact dimensions of this 125.10 x 64.80 x 13.92mm battery so I can confirm it fits my XTOOL device?

The replacement measures 125.10mm long, 64.80mm wide and 13.92mm thick, matching the original XTOOL PL3769124 2S pack for EZ500, i80 Pad, PS80, PS80E, X100 Pad 2, X100 Pad 2 Pro and X7 scanners.

Which step do installers most often miss when fitting the 7.4V pack into an XTOOL scanner?

Many forget to fully seat the decoded connector before closing the case; the chip must click into the board or the scanner will not recognise the 7200mAh cell.

How many charge cycles until the 53.28Wh lithium cell reaches full capacity?

The manufacturer states a new pack hits peak performance after two or three complete charge and discharge cycles.
