White rectangular in-wall timer switch with blue backlit display and push buttons

BN-LINK 7-Day Programmable In-Wall Timer Switch, 15 A 125 V, 18 On/Off Programs, Blue Backlight, ETL Listed

SKU CH-93B7-6R0P2

In-wall timer switch with 18 on/off programs, 7-day scheduling, blue backlight, random vacation mode and backup battery for lights, fans or motors

  • TypeWall Mount, Clamp, Blue Backlight
  • Voltage12
  • Amps15
  • Compatibility/Fitmentlights, fans, motors
  • Timing RangeScheduled and Manual
  • Pole ConfigurationThrough Hole
  • Blue backlight enables easy programming in low light
  • 18 on/off programs with 7-day scheduling fit any routine
  • Random mode shifts times by up to 30 minutes for a lived-in look
  • Rechargeable backup battery keeps settings during power outages
  • ETL listed and IP54 rated for indoor safety

Programmable In-Wall Timer Switch

The BN-LINK 7-day programmable in-wall timer switch controls lights, fans or motors on a 15 A 125 V circuit. It offers 18 on/off programs with one-minute resolution and a blue backlight for low-light readability. The unit carries ETL listing and an IP54-rated enclosure.

Installation Notes

Wiring requires a neutral conductor and suits both single-pole and 3-way (SPDT) configurations. The push-button interface mounts in a standard wall box measuring 12.5 cm by 8.2 cm by 6.2 cm. A rechargeable backup battery preserves schedules during power loss, and the random vacation mode offsets on/off times by up to 30 minutes.

Who This Suits

Homeowners wanting automated lighting schedules with daylight-saving adjustment and a visible display will find the feature set practical. Buyers without a neutral wire in the switch box or those needing more than 18 daily programs should look at other solutions.

Highlights

  • Blue backlight enables easy programming in low light
  • 18 on/off programs with 7-day scheduling fit any routine
  • Random mode shifts times by up to 30 minutes for a lived-in look
  • Rechargeable backup battery keeps settings during power outages
  • ETL listed and IP54 rated for indoor safety

Specifications

TypeWall Mount, Clamp, Blue Backlight
Voltage12
Amps15
Compatibility/Fitmentlights, fans, motors
Timing RangeScheduled and Manual
Pole ConfigurationThrough Hole
Horsepower1875 watts
Watts1875 watts
Number of ReceptaclesBlue Backlight, ?SU101D
Receptacle Type15 amps, 125 volts
Size/Dimensions12.5 cm x 8.2 cm x 6.2 cm
Color/FinishBlue
StyleClamp
Standards/CertificationsETL
Switch TypePush Button
Maximum Time SettingScheduled and Manual
Number of Poles3-way
Contact Form3-way
Enclosure TypeIP54, Wall Mount
Input Voltage125 volts
MountingWall Mount
Operating Temperature Range-4 degrees_fahrenheit to 140 degrees_fahrenheit
Featureslights, fans, motors
BrandBN-LINK
Model?SU101D
Item Count12 pack
Selling UnitBlue Backlight
Commercial/Residentiallights, fans, motors
Part Number?SU101D

Questions about this item

How do I confirm the BN-LINK timer switch is working correctly after installation?

After wiring the neutral and load connections, press the door to toggle between AUTO and MANUAL modes; the blue backlight should illuminate and the connected load will respond to your 18 programmed on/off schedules or manual presses.

What components are included with the BN-LINK 7-Day Programmable In-Wall Timer Switch and what must be purchased separately?

The package contains the timer switch unit (12.5 cm x 8.2 cm x 6.2 cm) with blue backlight and built-in rechargeable backup battery; you must supply your own 125 V neutral wire, wall box, and wire connectors for installation.

Which version of the BN-LINK timer switch should I choose for a standard 15 A 125 V lighting or fan circuit?

Select the single-pole/3-way compatible model rated 15 A, 125 V, 1875 W with IP54 enclosure — it supports up to 18 on/off programs, random vacation mode, and requires a neutral wire.
