Banner
Banner QS30LLP Long-Range Laser Sensor 0.2-18 m 10-30 V dc IP67 electrician tool
A long-range laser sensor detecting objects from 0.2 to 18 metres with bipolar NPN and PNP outputs, 10-30 V dc supply, IP67 housing and a 2 m cable
- TypeTest Equipment
- Color/FinishRed
- Item Count1 pack
- Selling UnitBox
- Parts3 Years
- Labor1 Year
- Detects targets up to 18 m away with 0.2 m minimum range
- Operates on 10-30 V dc supply for broad system compatibility
- IP67 and NEMA 6 rated housing withstands harsh environments
- Visible red Class 1 laser at 650 nm provides precise alignment
- Bipolar NPN and PNP outputs with 0.5 ms response time
Industrial long-range laser sensor
The Banner QS30LLP is a polarised retroreflective sensor designed for automation engineers who need reliable presence detection up to 18 m. It operates on a 10 to 30 V dc supply and provides both NPN and PNP discrete outputs in a single housing. The visible red Class 1 laser produces a small spot for precise alignment. An M30 threaded barrel allows direct mounting on standard brackets.
Sustained-operation reliability
The thermoplastic housing meets IP67 and NEMA 6, so the sensor withstands wash-down and temporary immersion without ingress. Operating temperature spans -10 °C to 50 °C at up to 95 percent relative humidity. A 0.5 ms response time and 70 µs repeatability remain stable over continuous duty cycles. The 2 m cable eliminates connector failure points in high-vibration machinery.
18 m polarised retroreflective range
The maximum sensing distance of 18 000 mm is the decisive figure for applications such as conveyor end-stop or pallet detection. Polarised optics reject shiny targets that defeat standard retroreflective sensors. Remote teach and a bargraph indicator simplify set-up without a separate programmer. Buyers who need longer range or background suppression must select a different sensing principle.
Highlights
- Detects targets up to 18 m away with 0.2 m minimum range
- Operates on 10-30 V dc supply for broad system compatibility
- IP67 and NEMA 6 rated housing withstands harsh environments
- Visible red Class 1 laser at 650 nm provides precise alignment
- Bipolar NPN and PNP outputs with 0.5 ms response time
Specifications
| Brand | BANNER |
|---|---|
| Model | QS30LLP |
| Type | Test Equipment |
| Color/Finish | Red |
| Item Count | 1 pack |
| Selling Unit | Box |
| Parts | 3 Years |
| Labor | 1 Year |
