Red rectangular sensor housing with M12 connector, 400 mm fixed-field range

Banner

Banner QS30FF400Q 400 mm electrician tool

SKU CH-D5CR-R8SP2 MPN QS30FF400Q

Fixed-field proximity sensor detects objects at 400 mm with bipolar NPN and PNP outputs on a 10-30 V dc supply

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Fixed-field background suppression eliminates false triggers at 400 mm range
  • Bipolar NPN and PNP outputs suit diverse control circuits from 10 to 30 V dc
  • IP67 and NEMA 6 ratings withstand dust, water jets and wash-down environments
  • Visible red 680 nm LED beam simplifies alignment and set-up checks
  • 2 ms response time and 500 µs repeatability deliver reliable high-speed detection

Fixed-field proximity sensor

The Banner QS30FF400Q is a rectangular background-suppression sensor with a 30 mm barrel and M30 mount. It detects objects at a fixed 400 mm range using a visible red LED at 680 nm wavelength. The thermoplastic housing carries an integral M12 5-pin Euro quick-disconnect and operates on 10-30 V dc supply voltage. Two discrete outputs provide both NPN and PNP switching in a single device.

Installers needing a single fixed sensing point

This unit suits applications where the detection distance must stay constant at 400 mm without teach-in or potentiometer adjustment. The bipolar output simplifies wiring when the controller type is not yet fixed. Buyers who need an adjustable sensing field or remote-teach capability should look at a different model.

400 mm fixed sensing distance

The sensing range is factory-set to 400 mm and cannot be changed in the field. If the target position varies or a longer or shorter distance is required, this sensor will not fit the application.

Highlights

  • Fixed-field background suppression eliminates false triggers at 400 mm range
  • Bipolar NPN and PNP outputs suit diverse control circuits from 10 to 30 V dc
  • IP67 and NEMA 6 ratings withstand dust, water jets and wash-down environments
  • Visible red 680 nm LED beam simplifies alignment and set-up checks
  • 2 ms response time and 500 µs repeatability deliver reliable high-speed detection

Specifications

BrandBANNER
ModelQS30FF400Q
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Does the box contain the M12 cable or must I order it separately?

The sensor ships with an integral M12 5-pin quick-disconnect; a mating cable is not included and must be purchased separately.

Is the 400 mm fixed-field version the only range available in this series?

This model is the 400 mm fixed-field variant; other QS30 models offer different sensing distances but are separate part numbers.

What does the 400 mm range mean when the sensor is mounted on a machine?

It detects objects up to 400 mm away with background suppression, ignoring surfaces beyond that distance, and responds in 2 ms.
