Red rectangular sensor housing with M30 mount and Euro-style quick-disconnect connector

Banner

Banner QS30ARXQ Electrician Tool 213 m Range 10-30V dc

SKU CH-D4NG-RHNCC MPN QS30ARXQ

Long-range opposed-mode receiver detects targets up to 213 m with 10-30 V dc supply and bipolar NPN/PNP outputs

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 213 m sensing range covers long-distance detection
  • 10-30 V dc supply fits standard industrial power
  • Bipolar NPN and PNP outputs simplify wiring
  • IP69 and NEMA 6 ratings withstand washdown environments
  • 5 ms response time enables fast machine cycles

High-Powered Opposed Receiver

The Banner QS30ARXQ is a WORLD-BEAM QS30 series receiver built for long-range opposed sensing. It detects an infrared beam across distances up to 213 m using an 875 nm LED source. The rectangular thermoplastic housing fits a standard M30 mount and connects through a 5-pin M12 Euro-style quick disconnect. Operating voltage spans 10-30 V dc with a 5 ms response time and 5000 µs repeatability.

Washdown Environments Needing Bipolar Output

This unit suits lines that demand both NPN and PNP signals from a single receiver in a light-operate configuration. The IP69 and NEMA 6 ratings support high-pressure washdown cycles at up to 70 °C and 95 % humidity. Buyers who require an emitter, remote teach capability, intrinsic safety or audible indication should look elsewhere because this receiver provides none of those features.

213 m Opposed Sensing Range

The maximum sensing distance of 213 m is the decisive specification; it defines whether the sensor spans the required gap between emitter and receiver. If the application gap exceeds this figure, the QS30ARXQ will not close the link.

Highlights

  • 213 m sensing range covers long-distance detection
  • 10-30 V dc supply fits standard industrial power
  • Bipolar NPN and PNP outputs simplify wiring
  • IP69 and NEMA 6 ratings withstand washdown environments
  • 5 ms response time enables fast machine cycles

Specifications

BrandBANNER
ModelQS30ARXQ
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Which emitter must I already have to pair with this QS30ARXQ receiver for opposed-mode sensing?

You need a WORLD-BEAM QS30 series emitter that operates at 875 nm infrared and provides a 213 m range to match this receiver.

Can I keep my existing M12 5-pin Euro-style cables when installing this sensor?

Yes, the integral M12 Euro quick-disconnect uses a standard 5-pin layout compatible with existing M12 cables.

How do I confirm the sensor is detecting the beam correctly after mounting?

Watch the bargraph indicator; it shows signal strength in real time so you can verify alignment and operation immediately.
