Red rectangular thermoplastic sensor with M12 connector and screw adjustment

Banner

Banner Q60BB6AFV1000Q 1000 mm range adjustable-field sensor electrician tool

SKU CH-EMZM-RXC9T MPN Q60BB6AFV1000Q

Adjustable-field background-suppression sensor detects objects up to 1000 mm with 10-30 V dc bipolar output, IP67 housing, M12 quick-disconnect and remote teach

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Adjustable background suppression up to 1000 mm sensing distance
  • Bipolar NPN and PNP outputs suit diverse control circuits
  • IP67 and NEMA 6 ratings protect against dust and water ingress
  • Visible red LED at 665 nm simplifies alignment and setup
  • Remote teach function enables configuration without physical sensor access

Adjustable-field sensor for electricians

The Banner Q60BB6AFV1000Q is a background-suppression proximity sensor with a 1000 mm maximum sensing distance. It suits electricians and automation technicians who need reliable object detection in industrial environments. The rectangular thermoplastic housing carries an M12 Euro-style quick-disconnect and a visible red LED beam at 665 nm.

Practical limits of the 10-30 V dc supply

The sensor operates from 10 to 30 V dc and draws power through a 5-pin M12 connector. It is rated IP67 and NEMA 6, so it withstands temporary immersion and dust ingress. Operating temperature spans -20 °C to 55 °C with up to 90 % relative humidity at 50 °C. A 150 ms power-up delay and 2 ms output response time set the timing floor.

Capacity and headroom for discrete output

Bipolar NPN and PNP outputs give wiring flexibility for light- or dark-operate modes. Screw adjustment sets the background-suppression distance, while remote teach allows configuration without opening the enclosure. Repeatability of 500 µs supports consistent switching. The sensor lacks intrinsic safety, IO-Link, DeviceNet, and encapsulation, so it is not suited for hazardous-area or networked architectures.

Highlights

  • Adjustable background suppression up to 1000 mm sensing distance
  • Bipolar NPN and PNP outputs suit diverse control circuits
  • IP67 and NEMA 6 ratings protect against dust and water ingress
  • Visible red LED at 665 nm simplifies alignment and setup
  • Remote teach function enables configuration without physical sensor access

Specifications

BrandBANNER
ModelQ60BB6AFV1000Q
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Should I choose the 1000 mm range version or a shorter-range model for my application?

This sensor has a maximum sensing distance of 1000 mm with adjustable background suppression. Select it when you need to detect objects up to one metre away while ignoring background surfaces; choose a shorter-range model only if your targets are consistently closer.

What does the 1000 mm sensing distance mean when the sensor is mounted on a machine?

The sensor will reliably detect a target up to 1000 mm away and can be adjusted to suppress backgrounds beyond that point. Its 2 ms response time and 500 µs repeatability ensure consistent detection on moving lines.

What does the M12 Euro quick-disconnect interface cap in practice?

The 5-pin M12 connector carries 10-30 V dc supply and bipolar NPN/PNP outputs. It is rated NEMA 6 and IP67, so the connection withstands wash-down and temporary immersion without signal loss.
