Red rectangular thermoplastic photoelectric sensor with M12 connector and adjustment screw

Banner

Banner Q60BB6AF2000Q photoelectric sensor 200-2000 mm 10-30 V dc

SKU CH-X3R0-V67DE MPN Q60BB6AF2000Q

Adjustable-field infrared sensor detects objects at 200-2000 mm with bipolar NPN/PNP output on 10-30 V dc, M12 quick-disconnect, IP67 housing and 2 ms response time

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Adjustable sensing range covers 200-2000 mm for flexible mounting
  • Bipolar NPN and PNP outputs simplify wiring into different control systems
  • IP67 and NEMA 6 ratings protect against dust and temporary immersion
  • Infrared LED with background suppression ignores reflective backgrounds reliably
  • Remote teach and screw adjustment enable quick setup without opening the housing

Industrial detection sensor

The Banner Q60BB6AF2000Q is an adjustable-field infrared photoelectric sensor built for presence detection at 200-2000 mm. It operates on a 10-30 V dc supply and provides bipolar NPN and PNP outputs through a 5-pin M12 Euro-style quick-disconnect. The rectangular thermoplastic housing carries NEMA 6 and IP67 ratings for harsh environments.

Upgrade from fixed-range sensors

This model replaces sensors that lack background suppression or require fixed sensing distances. The screw-adjustable background suppression lets you ignore objects beyond the target zone, making the jump worthwhile when reflective backgrounds cause false triggers on standard diffuse units. Remote teach capability further simplifies set-up changes without physical access to the sensor.

Straightforward M12 installation

Mount the sensor, connect the 5-pin M12 cordset, and set the sensing distance with the adjustment screw. The 150 ms power-up delay means the output stabilises quickly after supply voltage is applied. Ensure the acrylic lens stays clean; contamination is the most common cause of reduced range or erratic switching in dusty or wet conditions.

Highlights

  • Adjustable sensing range covers 200-2000 mm for flexible mounting
  • Bipolar NPN and PNP outputs simplify wiring into different control systems
  • IP67 and NEMA 6 ratings protect against dust and temporary immersion
  • Infrared LED with background suppression ignores reflective backgrounds reliably
  • Remote teach and screw adjustment enable quick setup without opening the housing

Specifications

BrandBANNER
ModelQ60BB6AF2000Q
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What size M12 Euro-style quick-disconnect connector does the Q60BB6AF2000Q use?

The sensor has an integral M12 Euro-style quick-disconnect with 5 pins for power and bipolar output wiring.

How do I set the sensing distance on this adjustable-field infrared sensor?

Turn the screw adjustment on the housing while the target is at the desired distance; the sensor teaches the background suppression point.

When should I replace the acrylic lens on this photoelectric sensor?

Replace the lens if it becomes scratched, clouded or cracked, as damage reduces the 2000 mm sensing range and IP67 sealing.
