Red rectangular laser distance sensor with M18 mount and M12 connector

Banner

Banner Q4XTULAF300-Q8 rugged laser distance sensor 300 mm

SKU CH-KHK6-QJF7F MPN Q4XTULAF300-Q8

Rugged laser distance sensor measures 25 to 300 mm with 0-10 V analog output and M12 connector

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 300 mm sensing range with 0-10 V analog output
  • Rugged stainless steel housing meets MIL-STD vibration and shock specs
  • Class 1 red laser for precise background suppression
  • Push-button and remote teach for fast setup
  • Operates on 12-30 V dc with integral M12 connector

Rugged laser distance sensor

The Banner Q4XTULAF300-Q8 is a rectangular stainless-steel sensor with an M18 mount and an integral M12 5-pin Euro connector. It emits a visible Class 1 red laser at 655 nm and provides an analog 0-10 V dc output proportional to target distance. The unit operates on 12-30 V dc supply and powers up in 750 ms.

Adjustable-field proximity sensing

This sensor suits automation tasks that need background and foreground suppression within a 25 mm to 300 mm window. It is not for applications requiring discrete switching outputs or IO-Link communication, nor for ranges beyond 300 mm.

Analog resolution and repeatability

Repeatability is better than 0.3 mm from 25 mm to 100 mm and better than 1 mm from 100 mm to 300 mm. Temperature drift is +/- 0.05 mm per °C up to 125 mm and +/- 0.35 mm per °C at 300 mm.

Highlights

  • 300 mm sensing range with 0-10 V analog output
  • Rugged stainless steel housing meets MIL-STD vibration and shock specs
  • Class 1 red laser for precise background suppression
  • Push-button and remote teach for fast setup
  • Operates on 12-30 V dc with integral M12 connector

Specifications

BrandBANNER
ModelQ4XTULAF300-Q8
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What power supply must I already have for the 12-30 V dc sensor?

Provide a 12-30 V dc source; the sensor draws power through its integral M12 5-pin Euro connector and needs 750 ms delay at power-up before reading.

Will the sensor mount on my existing M18 bracket?

Yes, the rectangular housing uses an M18 mount so it fits standard M18 brackets without adapters.

How do I verify the analog output is correct after wiring?

Measure 0-10 V dc on the analog pin; at 25-100 mm expect <0.3 mm repeatability, at 100-300 mm <1 mm, matching the stated resolution.
