Red rectangular stainless steel laser distance sensor with M18 mount and integral M12 connector

Banner

Banner Q4XTKLAF100-Q8 Rugged Laser Distance Sensor 100 mm range 10-30 V dc

SKU CH-9S2Y-MM2ST MPN Q4XTKLAF100-Q8

Rugged laser distance sensor measures up to 100 mm with Class 1 visible red beam and IO-Link output

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Precise detection up to 100 mm range
  • Reliable background suppression ignores unwanted targets
  • Rugged stainless steel housing withstands 100 G shock
  • IO-Link communication enables remote configuration
  • Visible red Class 1 laser simplifies alignment

Rugged Laser Sensor for 100 mm Range

The Banner Q4XTKLAF100-Q8 is a rectangular stainless-steel proximity sensor with background and foreground suppression. It operates on a 10-30 V dc supply and emits a visible red Class 1 laser beam at a 655 nm wavelength. The unit provides one PNP/NPN output with IO-Link communication plus one PNP discrete output rated to 100 mA. An integral M12 4-pin Euro connector handles all connections.

Check Power Supply and Mounting Clearance

Verify that your system can deliver a stable 10-30 V dc source and that the M12 4-pin Euro quick-disconnect matches your existing cabling. The sensor requires a 750 ms delay at power-up before it begins reliable detection. Ensure the rectangular housing with M18 mount threads fits the available mechanical envelope and that the 25 mm minimum sensing distance suits the target position. Confirm the operating temperature range meets the +/- 0.05 mm/°C temperature effect specification for your application.

Push-Button and Remote Teach Simplify Setup

The sensor includes push-button adjustments and a remote teach function so you can set the sensing window without a PC. PFM output is supported for applications requiring pulse-frequency modulation. Vibration resistance meets MIL-STD-202G Method 201A at 10 to 60 Hz with 0.06 inch double amplitude and 10G maximum acceleration. Mechanical shock survival is rated to MIL-STD-202G Method 213B Condition I at 100G across 18 total shocks while operating. These ruggedisation features allow the device to maintain performance in harsh industrial environments.

Highlights

  • Precise detection up to 100 mm range
  • Reliable background suppression ignores unwanted targets
  • Rugged stainless steel housing withstands 100 G shock
  • IO-Link communication enables remote configuration
  • Visible red Class 1 laser simplifies alignment

Specifications

BrandBANNER
ModelQ4XTKLAF100-Q8
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Does the sensor ship with a mounting bracket or an M12 cable, or must they be purchased separately?

The unit includes the sensor only; the M18 stainless-steel mount is integral, while a 4-pin Euro M12 cable and any bracket are sold separately.

Which sensing-distance version should I select for a 100 mm maximum range with 25 mm minimum?

This model provides a 100 mm maximum and 25 mm minimum sensing distance; choose it when the application fits within those limits.

What does the ±0.2 mm repeatability mean when the sensor is mounted on a vibrating line?

At 10-30 V dc the sensor delivers ±0.2 mm discrete repeatability, and vibration testing to MIL-STD-202G Method 201A (10-60 Hz, 0.06" double amplitude, 10 G) confirms the figure holds under shock.
