Red rectangular laser sensor with M12 connector and flush mount housing

Banner

Banner Q4XFPCOD310-Q8-REMOTE rugged laser distance sensor 310 mm range electrician tool

SKU CH-Q052-BY408 MPN Q4XFPCOD310-Q8-REMOTE

Rugged laser distance sensor measures up to 310 mm with visible red beam, PNP output and IP67/IP68/IP69 rating for harsh environments

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Accurate measurements up to 310 mm with visible red laser
  • Reliable detection from 35 mm minimum sensing distance
  • Durable stainless steel housing rated IP67, IP68, IP69
  • Withstands vibration and shock per MIL-STD-202G standards
  • Simple setup via push-button or remote teach adjustments

Rugged laser distance sensor for industrial sensing

The Banner Q4XFPCOD310-Q8-REMOTE is a Class 1 laser proximity sensor built for clear object detection in harsh environments. It suits electricians and automation engineers who need reliable background and foreground suppression on a production line. The stainless steel housing meets IP67, IP68 and IP69 ratings for wash-down duty. A visible red beam at 655 nm simplifies alignment during installation.

310 mm range with 35 mm minimum dead zone

The sensor switches a single PNP output up to 100 mA with saturation below 1.5 V across a 10-30 V dc supply. It reliably detects targets from 35 mm out to 310 mm, making it suited for short-range presence verification. Power-up delay is 750 ms and the unit withstands 100 G mechanical shock plus 10 G vibration per MIL-STD-202G. Operating temperature spans -25 °C to 75 °C.

Integral M12 connector and remote teach

A 4-pin Euro M12 quick-disconnect is moulded into the rectangular flush-mount body for fast wiring. Adjustments are handled by push button or remote teach input, allowing configuration without a PC. LED indicators provide local status feedback. The sensor ships as a single unit in a box with three years parts coverage and one year labour coverage.

Highlights

  • Accurate measurements up to 310 mm with visible red laser
  • Reliable detection from 35 mm minimum sensing distance
  • Durable stainless steel housing rated IP67, IP68, IP69
  • Withstands vibration and shock per MIL-STD-202G standards
  • Simple setup via push-button or remote teach adjustments

Specifications

BrandBANNER
ModelQ4XFPCOD310-Q8-REMOTE
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Will the sensor's 10-30 V dc power input work with my existing 24 V dc control cabinet supply?

Yes, the sensor operates on 10-30 V dc, so a standard 24 V dc supply is within range. The delay at power-up is 750 ms before the output becomes active.

How can I verify the sensor is detecting targets correctly after mounting it?

The unit has LED indicator displays that show output status. You can also use the remote teach function or the push-button adjustments to confirm the sensing window is set between 35 mm and 310 mm.

Does the box include the M12 cable or do I need to order a 4-pin Euro connector separately?

The sensor has an integral M12 4-pin Euro quick-disconnect connector. A mating cable is not included and must be purchased separately to complete the installation.
