Red rectangular ultrasonic sensor with 2m cable

Banner

Banner Q45ULIU64ACR Ultrasonic Sensor 100-1400mm 15-24Vdc 2m Cable

SKU CH-ED28-ETAAT MPN Q45ULIU64ACR

Versatile ultrasonic sensor detects objects from 100 mm to 1.4 m with selectable 0-10 V dc or 4-20 mA output

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Reliable detection from 100 mm to 1.4 m range
  • Flexible 0-10 V or 4-20 mA analog output options
  • Simple setup via teach button and DIP switches
  • Rugged PBT housing meets MIL-STD vibration and IEC 60947 shock standards
  • Output protection prevents false pulses and continuous overload damage

Versatile Ultrasonic Sensor 100-1400mm

The Banner Q45ULIU64ACR is an analog proximity sensor that detects objects from 100 mm to 1.4 m using ultrasonic time-of-flight technology. It operates on a 15-24 V dc supply and provides a selectable 0-10 V dc or 4-20 mA sourcing output through a 2 m cable. The rectangular PBT housing includes LED indicators and adjustment via a teach button and DIP switches.

Suited for industrial proximity sensing

This sensor suits applications requiring non-contact distance measurement within the 100 mm to 1400 mm range where analog voltage or current output is needed. It is not intended for users needing discrete switching outputs, IO-Link connectivity, or PC-configurable parameters. Buyers requiring a quick-disconnect fitting or a different housing style should look at alternative models.

Covers 100 mm to 1400 mm with 0.1% resolution

The device comfortably handles targets within the full sensing window, delivering analog resolution and repeatability of +/- 0.1% of measured distance with a minimum of +/- 0.25 mm. Performance degrades beyond the 1400 mm maximum range, and the 100 mm blind zone prevents reliable detection at closer distances. Temperature effects of 0.05% per degree Celsius apply across the range.

Highlights

  • Reliable detection from 100 mm to 1.4 m range
  • Flexible 0-10 V or 4-20 mA analog output options
  • Simple setup via teach button and DIP switches
  • Rugged PBT housing meets MIL-STD vibration and IEC 60947 shock standards
  • Output protection prevents false pulses and continuous overload damage

Specifications

BrandBANNER
ModelQ45ULIU64ACR
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What power supply voltage range must my system provide for the Q45ULIU64ACR sensor?

The sensor operates from a 15 to 24 V dc supply, so your power source must stay within that range.

Will the sensor's 2 m cable reach my existing controller without an extension?

The integral cable is 2 m (6.5 ft) long; measure the distance to your controller to decide if an extension is needed.

Which LED indication confirms the sensor is detecting a target within its 100 mm to 1.4 m range?

The onboard LED(s) change state when a target is detected inside the sensing window, showing the unit is working as intended.
