Rectangular red thermoplastic sensor with M12 connector

Banner

Banner Q45BB6DXQ5 Electrician Tool 3000mm 10-30Vdc IP67

SKU CH-3HSF-QVMT3 MPN Q45BB6DXQ5

A rectangular diffuse proximity sensor detecting objects up to 3000 mm with bipolar NPN and PNP outputs on a 10-30 V dc supply, housed in IP67-rated thermoplastic with an integral M12 quick-disconnect

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 3 m sensing range covers wide detection zones
  • 10-30 V dc supply fits common industrial power rails
  • Bipolar NPN and PNP outputs simplify wiring to different controllers
  • IP67 and NEMA 6P ratings protect against water and dust ingress
  • 2 ms response time enables fast machine-cycle decisions

Product identity

The Banner Q45BB6DXQ5 is a rectangular diffuse proximity sensor designed for industrial automation. It detects objects up to 3000 mm away using an infrared LED beam and operates on a 10-30 V dc supply with bipolar NPN and PNP outputs.

Ideal users and limits

This sensor suits engineers who need a rugged IP67 and NEMA 6P rated device for presence detection in wet or dusty environments. It is not for applications requiring background suppression, laser precision, or remote teach functionality.

Installation notes

The unit connects via an integral M12 4-pin Euro quick-disconnect and mounts using its 30 mm barrel diameter. A 100 ms power-up delay and potentiometer adjustment are standard; misalignment or contamination of the acrylic lens can reduce the effective sensing range.

Highlights

  • 3 m sensing range covers wide detection zones
  • 10-30 V dc supply fits common industrial power rails
  • Bipolar NPN and PNP outputs simplify wiring to different controllers
  • IP67 and NEMA 6P ratings protect against water and dust ingress
  • 2 ms response time enables fast machine-cycle decisions

Specifications

BrandBANNER
ModelQ45BB6DXQ5
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What power supply voltage range does the Q45BB6DXQ5 sensor require to operate?

The sensor operates on a 10-30 V dc power supply, so any source within that range will power it correctly.

Can the sensor's bipolar NPN and PNP outputs connect directly to a legacy PLC input card that only accepts NPN signals?

Yes, the NPN output can be wired to the NPN input card while the PNP output remains unused; both outputs share the same 10-30 V dc supply.

After wiring the M12 4-pin connector and applying power, how can I verify the sensor is detecting objects at its 3000 mm range?

The indicator LEDs will change state when an object enters the diffuse sensing beam, confirming the output is switching at the set distance.
