Rectangular red thermoplastic sensor with mini quick-disconnect and potentiometer adjustment

Banner

Banner Q45BB6DXQ Rugged Rectangle Sensor 3000 mm Range 10-30 V dc

SKU CH-0FMY-PZRKT MPN Q45BB6DXQ

Rugged rectangular diffuse sensor detects objects up to 3000 mm with bipolar NPN and PNP outputs on 10-30 V dc

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 3 m sensing range covers long-distance detection
  • 10-30 V dc supply fits standard industrial power
  • NEMA 6P and IP67 ratings resist harsh environments
  • 2 ms response time enables fast machine cycles
  • Bipolar NPN and PNP outputs simplify wiring

Rugged Rectangle Sensor 3000 mm Range

The Banner Q45BB6DXQ is a diffuse proximity sensor built for industrial detection tasks. Its rectangular thermoplastic housing meets IP67 and NEMA 6P ratings for harsh environments. The unit operates on 10-30 V dc supply voltage and provides bipolar NPN and PNP discrete outputs. It suits automation engineers needing reliable presence sensing at distance.

3 m Sensing Distance Limits

Maximum sensing distance reaches 3000 mm using an infrared LED beam. The diffuse mode detects targets without a separate reflector, but range varies with target colour, size and surface finish. Response time is 2 ms with 500 µs repeatability. Operation spans -40 °C to 70 °C at up to 90 % relative humidity. Excess ambient light or heavy contamination can reduce effective range.

Mini 4-pin Quick-Disconnect Install

Connection uses an integral 7/8 in mini quick-disconnect with four pins for fast wiring. A potentiometer allows sensitivity adjustment without tools. The 100 ms power-up delay prevents false triggers during start-up. Common issues include misalignment on low-reflectivity targets and cable strain on the mini QD fitting. Ensure the mating cordset matches the 4-pin pinout before powering the sensor.

Highlights

  • 3 m sensing range covers long-distance detection
  • 10-30 V dc supply fits standard industrial power
  • NEMA 6P and IP67 ratings resist harsh environments
  • 2 ms response time enables fast machine cycles
  • Bipolar NPN and PNP outputs simplify wiring

Specifications

BrandBANNER
ModelQ45BB6DXQ
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Should I pick the 3000 mm range model or a shorter-range version?

The 3000 mm range covers the longest detection distance in this series; choose it only if your target can be that far away.

What does the 3000 mm range mean once the sensor is mounted on a machine?

It detects objects up to 3 metres away under standard conditions; actual distance varies with target size, colour and surface finish.

What does the 10-30 V dc supply and 4-pin Mini QD interface cap in practice?

The sensor works on any 10-30 V dc source and the 4-pin 7/8 in. Mini quick-disconnect carries both NPN and PNP outputs simultaneously.
