Black cylindrical optical touch button with M30×1.5 thread and 2m cable

Banner

Banner OTBVN6 optical touch button 10-30V dc NPN IP66 M30×1.5 2m cable

SKU CH-HEXJ-8FNJZ MPN OTBVN6

An M30 optical touch button with 10-30 V dc supply, complementary NPN output, IP66 rating and a 2 m cable

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Optical touch actuation with no moving parts
  • Operates on 10-30 V dc supply voltage
  • Complementary NPN output for flexible wiring
  • IP66 and NEMA 4X rated for harsh environments
  • 2 m cable with M30 × 1.5 mounting thread

Momentary optical touch button

The Banner OTBVN6 is a single-point optical touch button designed for industrial control panels and machine interfaces. It operates on a 10-30V dc supply and provides complementary NPN output for direct integration with PLC inputs. The momentary actuation suits start, stop or jog functions where a brief touch triggers a single control cycle.

IP66 polysulfone housing with M30 thread

The black thermoplastic polysulfone housing carries an IP66 and NEMA 1, 3, 4, 4X, 12, 13 rating for wash-down and outdoor environments. A 2m (6.5ft) four-conductor cable exits the base for hard-wired installation. The M30 × 1.5 mounting thread allows secure panel fitting without additional brackets, while the 59.9 x 43.2 x 48.0 mm body fits standard cut-outs.

Replaces mechanical push-buttons in harsh areas

This unit upgrades mechanical switches that wear, jam or corrode in wet, dusty or chemically exposed settings. Optical actuation removes moving parts, extending service life where vibration or frequent cycling cause contact failure. It is not suited for applications requiring maintained latching action or audible feedback, nor for hazardous-area zones needing intrinsic safety certification.

Highlights

  • Optical touch actuation with no moving parts
  • Operates on 10-30 V dc supply voltage
  • Complementary NPN output for flexible wiring
  • IP66 and NEMA 4X rated for harsh environments
  • 2 m cable with M30 × 1.5 mounting thread

Specifications

BrandBANNER
ModelOTBVN6
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What does the 10-30V dc NPN interface mean for wiring and PLC compatibility?

The sensor runs on 10-30V dc and provides complementary NPN outputs with four conductors, so it connects directly to sinking PLC inputs without a separate relay.

Will the M30×1.5 mounting thread fit standard 30 mm panel cut-outs?

Yes, the M30×1.5 thread matches common 30 mm holes; the 59.9×43.2×48.0 mm body and saddle base mount let it sit flush in panels up to the thread depth.

How is the 2 m cable terminated and what is the common wiring mistake?

The 2 m (6.5 ft) cable has four flying leads — brown for 10-30V dc, blue for 0 V, black and white for the complementary NPN outputs; the frequent error is swapping the two output wires, which reverses the NO/NC logic.
