Red rectangular sensor with M12 connector and M18 mount

Banner

Banner MIAD9DQ Mini-Beam diffuse sensor 380 mm 5-15 V dc M12 4-pin IP67

SKU CH-VTN0-QYJA6 MPN MIAD9DQ

A diffuse proximity sensor detecting objects up to 380 mm with a 5-15 V dc supply and M12 4-pin connector, rated IP67 and NEMA 4X for harsh environments

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 380 mm diffuse sensing range for reliable object detection
  • 5-15 V dc supply voltage suits standard industrial power
  • M12 4-pin quick-disconnect enables fast installation
  • IP67 and NEMA 4X ratings withstand washdown and dust
  • Intrinsically safe design approved for hazardous-area use

Mini-Beam Diffuse Sensor 380 mm

The Banner MIAD9DQ is a rectangular diffuse proximity sensor with an M18 mounting barrel. It operates on a 5-15 V dc supply and provides a NAMUR constant-current output through an integral M12 4-pin quick-disconnect. The infrared LED beam detects objects up to 380 mm away, making it suitable for industrial automation and hazardous-area installations.

Range 380 mm and Environmental Headroom

The sensor reliably detects targets within its 380 mm maximum sensing distance and responds in 5 ms. It functions across a -40 to 70 °C temperature range and withstands 90 % relative humidity at 50 °C. The IP67 and NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13 ratings protect against dust, water immersion, and washdown environments. Applications requiring longer range or faster response will need a different model.

Integral M12 Connector and Potentiometer Adjustment

The built-in M12 4-pin Euro quick-disconnect simplifies wiring and replacement in the field. A potentiometer on the housing allows manual sensitivity adjustment for the diffuse sensing mode. The unit is encapsulated for durability and carries intrinsic safety approval for hazardous locations. No remote teach, timing functions, or IO-Link communication are provided.

Highlights

  • 380 mm diffuse sensing range for reliable object detection
  • 5-15 V dc supply voltage suits standard industrial power
  • M12 4-pin quick-disconnect enables fast installation
  • IP67 and NEMA 4X ratings withstand washdown and dust
  • Intrinsically safe design approved for hazardous-area use

Specifications

BrandBANNER
ModelMIAD9DQ
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Will the M12 4-pin quick-disconnect on this sensor plug into the existing M12 cables on our older Banner controllers?

Yes, the integral Euro-style M12 4-pin connector matches the industry-standard pinout used on legacy Banner controllers, so existing cables connect directly without adapters.

How can I verify the MIAD9DQ is operating correctly after wiring it to a 5-15 V dc supply?

Apply power within the 5-15 V dc range; the built-in indicator LEDs will show target detection status, and the NAMUR current output will shift between high and low states as objects enter or leave the 380 mm diffuse sensing zone.

Does the box include the M12 mating cable or mounting bracket, or must they be ordered separately?

The package contains only the sensor unit (part 34625); the M12 mating cable and any M18 mounting hardware are sold separately.
