Rectangular zinc-alloy sensor, red finish, M12 quick-disconnect, Class 2 visible red laser

Banner

Banner LTF12UC2LDQ Long-Range Time-of-Flight Laser Sensor electrician tool

SKU CH-9QNQ-BKFN3 MPN LTF12UC2LDQ

Measures distance from 50 mm to 12 000 mm with a Class 2 visible red laser and provides 0-10 V analog plus configurable NPN/PNP discrete outputs

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Long-range detection up to 12000 mm with Class 2 red laser
  • Accurate proximity sensing from 50 mm using time-of-flight technology
  • Flexible 12-30 V dc power input suits industrial supplies
  • Configurable NPN or PNP discrete output plus 0-10 V analog
  • Rugged zinc alloy housing withstands 30 G shock and vibration per MIL-STD-202G

Long-range time-of-flight laser sensor

The Banner LTF12UC2LDQ is a Class 2 visible red laser sensor designed for industrial proximity detection. It operates on a 12-30 V dc supply and delivers both analog and discrete outputs from a rectangular zinc alloy die-cast housing. This new unit suits automation engineers who need precise distance measurement in a rugged package.

Sensing range 50 to 12000 millimetres

The sensor measures targets from 50 mm up to 12000 mm using time-of-flight technology with a 660 nm laser beam. Analog resolution and discrete repeatability are rated at 1 mm while temperature effect is typically 0.25 mm per degree Celsius. A 2000 ms power-up delay ensures stable start-up before readings begin.

M12 quick-disconnect with push-button teach

Connection is via a 5-pin M12 Euro quick-disconnect for fast installation in control cabinets or on machines. Outputs are NPN/PNP configurable with saturation voltages below 1.6 V and 3 V respectively at 100 mA. Adjustments are made through push-button or remote teach without a PC while the housing meets MIL-STD-202G vibration and IEC 60947-5-2 shock requirements.

Highlights

  • Long-range detection up to 12000 mm with Class 2 red laser
  • Accurate proximity sensing from 50 mm using time-of-flight technology
  • Flexible 12-30 V dc power input suits industrial supplies
  • Configurable NPN or PNP discrete output plus 0-10 V analog
  • Rugged zinc alloy housing withstands 30 G shock and vibration per MIL-STD-202G

Specifications

BrandBANNER
ModelLTF12UC2LDQ
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What does the 12000 mm maximum sensing distance mean when the sensor is installed on a machine?

The sensor can detect objects up to 12 metres away using its Class 2 visible red laser at 660 nm wavelength.

How does the M12 quick-disconnect interface limit the wiring options?

The integral 5-pin M12 Euro connector carries both the 0-10 V analog output and configurable NPN/PNP discrete signals.

What mounting provisions does the rectangular zinc alloy housing provide?

The die-cast rectangular body meets MIL-STD-202G vibration and IEC 60947-5-2 shock requirements for industrial mounting.
