Red cylindrical rotary encoder with axial cable, 250mm wheel, IP50 rated

Autonics Corp

Autonics Corp ENC-1-3-N-24 rotary encoder incremental 1 pulse 12-24VDC IP50 electrician tool

SKU CH-8E1R-S26X7 MPN ENC-1-3-N-24

Incremental rotary encoder delivering 1 pulse per revolution at up to 5000 rpm with NPN open-collector output on 12-24 VDC supply

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Precise positioning with 1 pulse per revolution
  • High-speed response up to 180kHz maximum frequency
  • Handles rapid rotation at 5000rpm continuous operation
  • Dual-phase A/B output for direction detection
  • Reliable 12-24VDC power supply with NPN open collector

Rotary encoder for motion feedback

The Autonics ENC-1-3-N-24 is an incremental rotary encoder that delivers a single pulse per revolution. It operates on a 12-24VDC supply with a tolerance of ±5% and provides NPN open collector output on A and B phases. The unit is rated IP50 and specified for a maximum response frequency of 180kHz and a maximum allowable revolution of 5000rpm.

Integration into control systems

The encoder uses an axial cable connection for direct wiring into a controller or counter module. Its 12-24VDC input range allows it to share a common supply with many industrial sensors and PLCs. The NPN open collector outputs require pull-up resistors at the receiving device, which the installer must provide. A wheel diameter of 250mm and a 4:1 gear ratio define the mechanical coupling to the measured shaft.

Packaged for immediate installation

The product ships as a single unit in a box, ready to mount without additional components from the supplier. No software, configuration tools or mounting brackets are included in the package. The three-year parts and one-year labor coverage applies to the encoder itself, leaving cable routing, connector termination and pull-up resistor selection to the system integrator.

Highlights

  • Precise positioning with 1 pulse per revolution
  • High-speed response up to 180kHz maximum frequency
  • Handles rapid rotation at 5000rpm continuous operation
  • Dual-phase A/B output for direction detection
  • Reliable 12-24VDC power supply with NPN open collector

Specifications

BrandAutonics
ModelENC-1-3-N-24
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What limits continuous high-speed operation?

The maximum response frequency is 180 kHz and the mechanical limit is 5000 rpm.

How much heat or noise does the encoder produce during all-day use?

It is a passive NPN open-collector sensor with IP50 protection, so it generates negligible heat and no audible noise.

What power supply and wiring must already be in place for it to work?

A 12-24 VDC source within ±5 % ripple and an axial cable connection are required.
