Anvil steel pipe saddle clamp socket weld half inch

Anvil

Anvil 0766260053 Pipe Saddle Socket Weld 1/2 In hand tool

SKU CH-45D7-MPWHG MPN 0766260053

Steel pipe saddle clamp for 1/2-inch socket-weld branch connections on 3/4 to 36-inch run pipe, rated to 3000 psi per MSS-SP-97 and ASME B16.11

  • TypeClamps
  • MaterialSteel
  • Weight0.3
  • Socket-weld outlet rated for 3000 psi service pressure
  • Steel construction handles 3000 class piping systems
  • Fits 1/2 inch outlet on 3/4 to 36 inch run pipe
  • Meets MSS-SP-97 and ASME B16.11 design standards
  • Lightweight at .3 kg for easy handling

1/2 In Socket Weld Pipe Saddle

This Anvil pipe saddle provides a socket-weld branch outlet for half-inch pipe. It is manufactured from steel and rated for 3000 class service. The fitting conforms to MSS-SP-97 and ASME B 16.11 standards. It weighs .3 units and suits piping systems requiring a reinforced branch connection.

Fit for 3/4 to 36 In run pipes

The saddle accommodates nominal run pipe sizes from 3/4 In up to 36 In. It is intended for installers who need a socket-weld outlet on a half-inch branch line. Projects requiring a threaded, butt-weld or flanged outlet should select a different fitting type. Buyers needing a different branch size must choose another model.

Class 3000 pressure rating

The single specification that determines suitability is the 3000 pressure class rating. This defines the maximum allowable working pressure for the connection at ambient temperature. Verify that the system design pressure falls within this class before specifying the part. The steel construction and listed standards support this rating.

Highlights

  • Socket-weld outlet rated for 3000 psi service pressure
  • Steel construction handles 3000 class piping systems
  • Fits 1/2 inch outlet on 3/4 to 36 inch run pipe
  • Meets MSS-SP-97 and ASME B16.11 design standards
  • Lightweight at .3 kg for easy handling

Specifications

BrandAnvil
Model0766260053
TypeClamps
MaterialSteel
Weight0.3

Questions about this item

Does the Anvil 0766260053 pipe saddle come with any additional hardware or gaskets for the socket weld connection?

The fitting is supplied as a single steel component. Bolts, gaskets and welding consumables for the socket weld joint must be sourced separately.

When should I select the 1/2 In outlet size with a 3000 pressure class over other available ratings?

Choose this version when the branch line is 1/2 In nominal and the system design requires a 3000 class socket weld fitting rated to 3000 psi per MSS-SP-97 and ASME B 16.11.

What does the 3000 psi pressure rating mean once the saddle is welded onto a run pipe?

After a qualified socket weld, the branch connection is rated for 3000 psi at ambient temperature in accordance with MSS-SP-97 and ASME B 16.11 for the 3000 class.
