Black rectangular RFID card reader with textured ABS+PC finish, 116 by 75 by 17.3 mm, IP65 rated

ZKTECO

ZKTECO KR601 KR602 IC ID RFID Card Reader Outdoor Use office equipment

SKU CH-DBSQ-P05G8

Weather-resistant RFID card reader for access control, reading ID and M1 cards up to 10 cm with Wiegand 26/34-bit output

Models: Select KR601E+ID

  • Reliable card reading up to 10 cm distance
  • Fast decoding completes reads in under one second
  • IP65 rated for outdoor dust and water protection
  • Wide DC 9-12 V input suits varied power supplies
  • Wiegand 26/34 bit output integrates with access systems

KR601 KR602 RFID access reader

The ZKTECO KR601 KR602 is an outdoor RFID card reader built for access control, attendance and charging systems. It reads ID and M1 cards at up to 10cm range using a high-sensitivity RF circuit and embedded microcontroller. The IP65-rated ABS+PC housing withstands temperatures from -20°C to +65°C.

Wiegand output with external LED and buzzer control

The reader delivers 26 or 34 bit Wiegand data and provides two input ports for external LED and buzzer control. Dual-colour red and green LEDs plus an onboard beeper give immediate visual and audible feedback at the door. A single 9 to 12V DC supply drawing a maximum of 70mA powers the unit.

5 to 10cm read range decides suitability

The maximum read distance of 5 to 10cm determines whether the reader fits the intended mounting position and card presentation style. Installers must verify this range matches the physical layout before purchase.

Highlights

  • Reliable card reading up to 10 cm distance
  • Fast decoding completes reads in under one second
  • IP65 rated for outdoor dust and water protection
  • Wide DC 9-12 V input suits varied power supplies
  • Wiegand 26/34 bit output integrates with access systems

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the Wiegand 26/34 bit output need reconfiguration when the access controller is upgraded?

The reader outputs fixed 26 or 34 bit Wiegand data; any new controller must accept one of those formats or the wiring will need changes.

What limits continuous operation first — the 70 mA current draw or the IP65 seal?

The IP65-rated ABS+PC housing handles the -20 °C to +65 °C range, so the 70 mA draw at 9-12 V DC is the practical ceiling for sustained power budgeting.

How hot does the black ABS+PC case get when the reader runs all day outdoors?

The unit is rated for -20 °C to +65 °C ambient; the low 70 mA current keeps self-heating minimal, so surface temperature stays close to the surrounding air.
