White rackmount network switch with 48 RJ45 ports and four SFP ports, matte finish, front status LEDs

Ubiquiti Networks

Ubiquiti Networks USW-48-POE (195W) 48-port network switch

SKU CH-PQZ9-0PVV2 MPN USW-48-POE (195W)

A managed 48-port Layer 2 switch with 32 PoE+ ports, 195 W power budget, four SFP uplinks and silent fanless cooling

  • FormatRackmount
  • Network Management TypeManaged
  • Primary Ports48 x RJ45 + 4 x SFP
  • Primary Port SpeedTotal non-blocking throughput 52 Gbps Switching capacity 104
  • Primary Port Type(48) GbE RJ45 ports (4) 1G SFP ports
  • Management InterfaceEthernet In-Band

Model Standard 48 PoE

  • Fanless design enables silent operation in noise-sensitive areas
  • 32 PoE+ ports with 195 W budget power access points and cameras over one cable
  • 48 GbE RJ45 plus 4 SFP ports provide 52 Gbps non-blocking throughput
  • Managed Layer 2 features include VLAN, IGMP snooping, STP/RSTP and port isolation
  • Universal 100—240 V AC input simplifies deployment worldwide

48-Port Managed Switch with 195 W PoE

This rack-mountable Layer 2 switch provides 48 Gigabit RJ45 ports and four 1 Gbps SFP uplinks. Thirty-two RJ45 ports deliver IEEE 802.3af/at PoE+ with a total power budget of 195 W. The fanless design ensures silent operation in noise-sensitive environments. Non-blocking throughput reaches 52 Gbps with a 104 Gbps switching capacity.

Suited for PoE access points and cameras.

Network managers who need to power UniFi access points, IP cameras or VoIP phones over a single cable will find the PoE+ ports and 195 W budget convenient. The switch also supports VLANs, LACP aggregation, IGMP snooping and port isolation for traffic segmentation. Buyers requiring 10 Gbps fibre uplinks or Layer 3 routing should look at a different model.

195 W total PoE budget decides port density

The 195 W pool limits how many ports can simultaneously supply full PoE+ class power, so planners must calculate per-device draw before committing all 32 PoE ports. If the connected devices stay within the budget the switch delivers line-rate forwarding on every port at 77.38 Mpps. Exceeding the budget will cause some ports to negotiate lower power classes or remain unpowered.

Highlights

  • Fanless design enables silent operation in noise-sensitive areas
  • 32 PoE+ ports with 195 W budget power access points and cameras over one cable
  • 48 GbE RJ45 plus 4 SFP ports provide 52 Gbps non-blocking throughput
  • Managed Layer 2 features include VLAN, IGMP snooping, STP/RSTP and port isolation
  • Universal 100—240 V AC input simplifies deployment worldwide

Specifications

BrandUbiquiti Networks
SeriesNetwork Switch
ModelStandard 48 PoE
Part NumberUSW-48-POE (195W)
FormatRackmount
Network Management TypeManaged
Primary Ports48 x RJ45 + 4 x SFP
Primary Port SpeedTotal non-blocking throughput 52 Gbps
Switching capacity 104 Gbps
Forwarding rate 77.38 Mpps
Primary Port Type(48) GbE RJ45 ports
(4) 1G SFP ports
Management InterfaceEthernet In-Band
VLAN SupportYes
Jumbo FramesYes
PoEYes
Layer2
Layer 2 FeaturesIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Port MirroringYes
LEDsSystem Status
Ethernet PoE Speed/link/activity
SFP Link/activity
PoE Ports(32) PoE/PoE+ (Pins 1, 2+; 3, 6-)
PoE Power Budget195W
PowerUniversal input, 100—240V AC, 50/60 Hz
Max Power Consumption45W (Excluding PoE output)
Dimensions442 x 285 x 44 mm (17.4 x 11.2 x 1.7")
WeightWithout mounting brackets: 4.5 kg (10 lb)
With mounting brackets: 4.6 kg (10.2 lb)
CertificationCE, FCC, IC
Temperature-5 to 40° C (23 to 104° F)
Humidity10 to 90% noncondensing
Shipping weight5.92 kg
Package size528 × 432 × 127 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the 48-port model with 32 PoE+ ports or the 24-port model with 16 PoE+ ports?

The 48-port model provides 48 RJ45 ports with 32 supporting PoE+ and a 195 W power budget, while the 24-port model offers 24 RJ45 ports with 16 PoE+ ports and a 95 W budget. Choose based on how many powered devices you need to connect.

What does the 104 Gbps switching capacity mean for daily traffic?

The 104 Gbps switching capacity and 52 Gbps non-blocking throughput allow all 48 Gigabit RJ45 ports and 4 SFP ports to run at line rate simultaneously without packet loss, supporting full-duplex traffic across every connected device.

The switch has 4 SFP ports — what uplink speed do they actually support?

The four SFP ports operate at 1 Gbps each, providing fibre uplinks up to 1 Gbps; they do not support 10 Gbps SFP+ modules.
